Funn KINGPIN HANDLEBAR Installation And Use Manual

Thank you for choosing FUNN's KINGPIN handlebar for your mountain bike.

Please read these instructions thoroughly before attempting to install this item.

Following all ﬁtting instructions in order is required for compliance with FUNN's warranty policy.

tools required

． Hex keys

． KINGPIN Handlebar

FUNN handlebars are designed to be cut down to ﬁt your style, but when trimming carbon bars, special care is required, so

it's best to consult a professional.

For precise adjustments, follow the guide marks on the bar,

ensuring you don't cut below the inner-most mark for safety.

It's important to cut the same distance on both sides to

maintain balance. Remember, after cutting carbon bars, refrain

from using bar ends to ensure the integrity of your handlebars.

Carefully detach any components attached to the old handlebars, such as shifters, brake levers, grips, and bar ends.

Loosen and then remove the stem faceplate. Following this,

remove the old handlebars from the stem.

WWW.FUNNMTB.COM

KINGPIN HANDLEBAR 2024.01.30 / REV. 0

1 PC

KINGPIN HANDLEBAR

INSTALLATION AND USE

Table of Contents

Do you have a question about the KINGPIN HANDLEBAR and is the answer not in the manual?

Page 1 1 PC HANDLEBAR CUTTING FUNN handlebars are designed to be cut down to ﬁt your style, but when trimming carbon bars, special care is required, so it's best to consult a professional. For precise adjustments, follow the guide marks on the bar, ensuring you don't cut below the inner-most mark for safety.
Page 2 Then, tighten the stem's faceplate in a cross pattern for even pressure distribution. Reattach the components you previously removed onto the new handlebar, ensuring they are positioned for optimal comfort and accessibility. WWW.FUNNMTB.COM KINGPIN HANDLEBAR 2024.01.30 / REV. 0...
