NOTICE
These general procedures will be referenced in other
sections throughout the manual.

SeTUp JUMper INSTallaTIoN

NOTICE
Machine must be secured prior to installation. Installing
setup jumper will:
• Disable Cold Start
• Increase Engine RPM to Full operating RPM
• Disable Stroke Follower
1. Remove Cap (P\N: 22812) on P24 of main harness
(under foot platform).
2. Install Setup Jumper (P/N: 32007 on P24).
DISaBle
(If Setup Jumper is not
installed)
re-eNaBle
(If disabled via service
tool)
page 12 — HTXD6i/STXD6i Trowel • SeTUp, aDJUSTMeNTS aND CalIBraTIoNS — rev. #0 (03/14/13)
Table 2. Disable and re-enable options
Cold Start
Stroke Follower
Cold Start
Stroke Follower

General procedures

reMove SeTUp JUMper
(If installed).
1. Remove Setup Jumper (P\N: 32007) from P24 of main
harness.
2. Re-install Cap (P\N: 22812) on P24 of main harness.
1. Open service tool.
2. Click "machine setup" button on main page.
3. Click "Cold Start" button under Setup Menu.
4. Click check box next to Disabled.
5. Press Download Button.
1. Open service tool.
2. Click "machine setup" button on main page.
3. Click "Stroke Cont." button under Setup Menu.
4. Click button "Disable Stroke Follower".
1. Open service tool.
2. Click "machine setup" button on main page.
3. Click "Cold Start" button under Setup Menu.
4. Uncheck box next to Disable.
5. Press Download Button.
1. Open service tool.
2. Click "machine setup" button on main page.
3. Click "Stroke Cont." button under Setup Menu.
4. Click button "Enable Stroke Follower".
