NOTICE
The following machine information should be recorded
on Machine Information and Maintenance Log for unit
service tracking and for filing any warranty claims.

MoDel

1. Enter appropriate model:
„ HTXD6i — for 6-blade HTX
„ STXD6i — for 6-blade STX

SerIal NUMBer

2. Machine Serial Number — as shown on serial tag.
3. engine Serial Number — located on top of engine
(E/N) (Figure 1) or stamped on side of block (Figure 2).
Figure 1. Engine Serial Number Location 1
Figure 2. Engine Serial Number Location 2
HTXD6i/STXD6i Trowel • SeTUp, aDJUSTMeNTS aND CalIBraTIoNS — rev. #0 (03/14/13) — page 11

macHine information

4. pump Serial Number — located on sticker on pump
(Figure 3). The lower number is the pump serial number.
Figure 3. Pump Serial Number Location
5. Motor Serial Number — located on sticker on top of
hydraulic motors (Figure 4).The lower number is the
motor serial number.
NOTICE
If lot number is listed instead of the serial number,
record lot number.
Figure 4. Motor Serial Number Location

prograM ID

The program ID is recorded in the QA Sheet that is shipped
with the unit.
