Summary of Contents for HealTech Electronics Advanced Rider Assistant
Page 1
Advanced Rider Assistant Supplementary Manual Aprilia Dorsoduro 750 non-ABS Factory 2008-2015 (ARA-1 + ARA-K2F + ARA-DD11) Secure the bike on a stand. Remove the seat. Remove the side fairings from the fuel tank. Remove the fuel tank. Plug the ARA connectors in-line with the ignition coil connectors.
Page 2
Advanced Rider Assistant Supplementary Manual Aprilia Dorsoduro 750 non-ABS Factory 2008-2015 (ARA-1 + ARA-K2F + ARA-DD11) Connect the ARA Black wire terminal to the battery negative terminal. Mount the supplied disk and wheel speed sensor at the front wheel. (For the disk mounting see the Front Disc Mounting all bikes without ABS supplementary manual.Reinstall the brake...
Page 3
Advanced Rider Assistant Supplementary Manual Aprilia Dorsoduro 750 non-ABS Factory 2008-2015 (ARA-1 + ARA-K2F + ARA-DD11) Mount the supplied disk and wheel speed sensor at the rear wheel. (For the disk mounting see the Rear Disc Mounting all bikes without ABS supplementary manual.
Page 4
Advanced Rider Assistant Supplementary Manual Aprilia Dorsoduro 750 non-ABS Factory 2008-2015 (ARA-1 + ARA-K2F + ARA-DD11) Mount the switch onto the handlebar. Mount the LED indicator on the dashboard. Typical position for the ARA module. Secure the unit properly. w w w . h e a l t e c h - e l e c t r o n i c s . c o m...
