Advanced Rider Assistant
Supplementary Manual
Honda ST1300 ABS Pan European 2002-2016 (ARA-1 + ARA-K2T)
Secure the bike on a stand.
Remove the seat.
Lift up or remove the fuel tank.
Locate the ignition coil connectors on the
left side under the side fairing.
Take off the Yellow/Blue terminal from
the coil.
Plug the ARA White connectors in-line
with the ignition coil terminals.
w w w . h e a l t e c h - e l e c t r o n i c s . c o m
1/3
