OVERVIEW
This chapter describes the steps required to assemble the Radiographic Table and
how to install the completed assembly in your facility, including making all required
electrical connections.
NOTE
Examine all car-
tons and crates
carefully at time
of delivery. If
damage is appar-
ent, have deliv-
ery driver write a
"Damaged Ship-
ment Note" on
copies of freight
bill, sign it, and
file appropriate
carrier claim.
Should you dis-
cover concealed
damage, immedi-
ately notify the
transporting
agent and ask
for an
"Inspection of
Damage". Carrier
will not accept
concealed dam-
age claim if filed
after 15 days
from date of
receipt of mer-
chandise.
Model QT-730 Radiographic Table
Chapter 3 Assembly & Installation
REQUIRED TOOLS AND MATERIALS
The following tools and materials are required to complete the assembly and
installation procedures:
Socket Wrench Set
•
Assorted Phillips and slot blade screwdrivers
•
Drill (and masonry bit if concrete construction)
•
Double bubble level (min. 18 inches in length)
•
UNPACKING
The Radiographic Table is shipped in separate shipping containers as follows:
Table Base Assembly
•
Table Top Assembly with Receptor Cabinet (i.e., fixed grid cabinet or
•
bucky)
Manual, hardware bag, etc.
•
Open the crate or carton marked "packing list enclosed" first. Locate and re-
move the packing list. Use the list as a guide to opening remaining cartons.
Do not dispose of packing material until packing list is matched with actual
parts received. If any damaged parts are found, notify the shipping or freight
company immediately (the manufacturer is relieved of any responsibility for
damage during shipment after unit is picked up by the carrier). Should there
be a shortage of parts, notify Quantum Medical Imaging's Service Department.
