Model QT-730 Radiographic Table
PHYSICAL SPECIFICATIONS
The following are physical specifications for the Radiographic Table (see Figure
2):
Tabletop Specifications
Length:
•
Width:
•
Height:
•
Material Type:
•
Density:
•
Tabletop-to-Film
•
plane distance:
*Note: Reduced length down to 60 inches (1524 mm) is available; reduces
longitudinal travel distance
Table Base Specifications
Width:
•
Depth (measured at
•
base bottom):
Table Specifications
• Total Table Weight:
Maximum patient
•
weight capacity:
Other Specifications
• Receptor Types:
Bucky Weight (w/grid
•
and cassette tray):
Collimator compatibility:
•
Chapter 2 Specifications
74.0 inches (1879.6 mm)*
28.0 inches (711.2 mm)
31.75 inches (806.5 mm)
Fiber Resin (phenolic)
less than 1.0 mm Al
from 2.3 to 2.9 inches (58.4 to
73.7 mm)
38.0 inches (965.2 mm)
26.5 inches (673.1 mm)
175 lbs. (79.38 kg)
650 lbs. (294.8 kg)
14 x 17 fixed grid
14 x 17 bucky
35 - 40 lbs. (typical)
Manual, Selectable or Automatic
7
