APPENDIX A - SPECIFICATIONS

Sensor type:
Max. Range
User Settings Range
Zero Drift
Repeatability
Linearity
Resolution
Response Time (1)
Accuracy
Sensor Life
(1) Response time to 90% full signal value for applied concentration
(2) Sensor life typical for use at standard temperature and pressure with occasional exposure to gas of interest
Output:
Display:
Relays (Optional):
Analog Output (Optional)
Signal Output:
Input:
Remote Alarm Reset:
Electrical Data:
Power consumption:
Connection type:
Input voltage:
Operating Range:
o
Ambient Temp ( F)
o
Ambient Temp ( C)
Relative Humidity
Enclosure:
Material - Standard:
Material - Stainless Steel Option
Dimensions:
(H x W x D)
Weight:
Housing:
Electrical Classification
Performance:
FM Approved
Approvals:

7. APPENDICES

Electrochemical
5100-03-IT O2 5100-04-IT CO
0-25 %Vol 0-1000 PPM
0-100, 0-500, variable
+/- 0.1% +/- 1 PPM
+/- 0.2% +/- 1 PPM
+/- 0.2% +/- 1 PPM
+/- 0.1% 0.5 PPM
<10 sec <25 sec.
+/- 0.2% +/- 1 PPM
2 years 2 years
Fixed and Scrolling LED
8 Amp, High Alarm, Low Alarm, 2 Amp Trouble all SPDT
Analog 4-20 mA (Trouble 0 mA, Calibration 1.5 mA)
Sentry bus
Serial RS-485 Modbus RTU
Normally open digital input (supervised or non-supervised)
2 watts
3 wire
24 VDC nominal: 10-30VDC
5100-03-IT O2 5100-04-IT CO
o
5 to 122 F -4 to 122
o
-15 to 50 C -20 to 50
5 – 99% 5 – 99%
Polyester powder-coated, sand-cast, copper-free aluminum
316 Stainless Steel (FM approval pending)
7.5 x 5.0 x 4.8 inches Al, 7.5 x 5.0 x 4.4 inches SS
(21.6 x 12.7 x 12.2 cm)
2.7 lb. (1.3 Kg) (standard Aluminum enclosure)
5.4 lb. (2.6 Kg) 316 Stainless Steel
NEMA 4X
Explosion proof, Class 1, Div. I, Groups B, C, D
Class I, Zone 1, groups IIB+H2 IP66
Performance and Safety Approval Pending
Page: 29
Model 5100-XX-IT Toxic Gas Sensor Module
5100-05-IT H2S
0-100 PPM
0-10, variable
+/- 0.5 PPM
+/- 1 PPM
+/- 1 PPM
0.1 PPM
<30 sec.
+/- 0.5 PPM
2 years
5100-05-IT H2S
o o
F -40 to 122
o o
C -40 to 50 C
5 – 99%
5100-06-IT Cl2
0-10 PPM
0-5, variable
+/- 0.5 PPM
+/- 0.5 PPM
+/- 0.5 PPM
0.1 PPM
<60 sec
+/- 0.5 PPM
2 years
5100-06-IT Cl2
o
F -4 to 122 F
o
-20 to 50 C
5 – 99%
