RUKO F11 Drone Manual
Download App
Charge the Batteries
Prepare for Use
Select an Open Flight
Start the Aircraft
Press and hold the button until the Aircraft plays startup sound.
Short-press to power on the Transmitter.
Pair the Transmitter with the Aircraft
Push up the left stick and the Transmitter plays a sound "di".
Push down the left stick and the Transmitter plays another sound "di".
Once successfully paired, white light will stay on.
Connect to Wi-Fi
Connect the mobile device to the Aircraft's Wi-Fi and enter the App operation page. Please refer to user manual for more details.
Calibrate the Compass
Rotate the aircraft horizontally 360. (About 1-2 turns)
Rotate the aircraft vertically 360. (About 1-2 turns)
Calibrate the Gyroscope
- Push joysticks to 11 & 1 o'clock position. (About 2 seconds)
Search for GPS Automatically
Tips:
- The searching time depends on the flight environment.
- If unsuccessful, the motors can't be started.
Start the Motors
- Push joysticks to 5 & 7 o'clock position. (About 2 seconds)
Take off
- Push up the left stick or press the "Auto Takeoff" button.
NEW TO FLYING DRONES?
Check the Flight Guide in the App
Search "Ruko F11 Quick Start" on YouTube for First Flight
Scan QR Code for More Tech and Video Support
CONTACT US FOR MORE TECH SUPPORT
Rukodrone@gmail.com
+1 (949) 394 - 4635 (Available from 6pm to 3am PDT)
Common Problems and Solutions
| Question | Reason | Solutions |
| The motors cannot be started | Weak GPS signal | Turn on the Aircraft in an open area with strong GPS signal |
| The red light stays on | The Aircraft has low battery. Please charge the battery in time | |
| The pink light stays on | The compass is not calibrated. Please refer to the "Calibration Before Flight" section of the user manual | |
| The left and right joystick are in place | Push the left and right joysticks simultaneously to 5 o'clock and 7 o'clock for 2 seconds | |
| Unstable flight | Flying too low; affected by airflow | Please fly the Aircraft above 9.84ft(3 meters) |
| The gyroscope is not calibrated | Place the Aircraft on a horizontal surface and conduct gyroscope/horizontal calibration. Please refer to the "Calibration Before Flight" section of the user manual | |
| The propellers become deformed and incomplete | Replace the propellers with new ones | |
| GPS signal is unstable. Flying near buildings and in obstructed places | Please fly the Aircraft in an open area free of obstacles within the circle of radius 32.81 ft(10 meters) | |
| The flight direction is opposite or inconsistent with the remote control | The Aircraft is placed incorrectly before takeoff | Before takeoff, keep the camera ahead and the tail towards the pilot |
| Get into Headless mode | Turn off headless mode | |
| The Aircraft fall suddenly | Emergency stop is used | Do not use the emergency stop in non-emergency situations to avoid unnecessary losses |
| Out of control, spinning around on its own, abnormal sound | The Transmitter signal is interfered or the Aircraft exceeds the range of remote control | Please fly the Aircraft outdoors without interference, and ensure that it is within a controllable range |
| Compass interference | Please manually land the drone in time and calibrate the compass. Please make sure to fly away from the buildings, trees, power lines, and signal towers | |
| The propellers become deformed and incomplete | Replace the propellers with new ones | |
| The camera cannot be adjusted up and down | There are obstacles between the camera and the ground. When the Aircraft is turned on, the camera swings down for self-checking and the camera got stuck on obstacles | Restart the drone and ensure that there is enough space under the camera |
| Recalibrate the gyroscope, and the camera will recheck itself as well | ||
| The camera will not point directly forward | This is the unique design of the camera, not a malfunction | Prevent propellers from affecting photography. Adjust the angle of the camera and let it point straight ahead to acquire best shooting experience |
| Video freezes, image transmission distance is short | The Aircraft is out of Wi-Fi range | Fly the Aircraft within the range of the Wi-Fi |
| WiFi image transmission signal interference | Fly the Aircraft in an unobstructed open area free of buildings, high-voltage wires and signal towers | |
| The transmitter and the mobile phone are not pointed at the direction of the drone | Point the Transmitter and the mobile device at the flying direction of the Aircraft to maintain the strongest signal connection | |
| Phone performance freezes | Close unused apps running in the background to maintain the best performance of the phone | |
| App does not display the interface | The phone is not connected to Wi-Fi | Connect your mobile device to the Wi-Fi: Ruko***** |
| The phone version is too low | Android 6.0 and above, IOS 10.02 and above | |
| When connecting to the drone' s | Set the Wi-Fi correctly | |
| WiFi, the network is not set or set incorrectly | Turn the phone to airplane mode | |
| VPN switch is turned on | Turn off the VPN switch | |
| Phone cannot connect to Wi-Fi | It is the first time to connect your phone to the Wi-Fi | Try connecting a few more times or restart the phone |
| The WiFi name is not displayed in the list | The phone is a single band phone | Use the dual band devices that support both 2.4 GHz and 5 GHz/5.8 GHz |
| WiFi has not been activated | Wait for about 30 seconds after turning on the Aircraft and keep refreshing the Wi-Fi list while the Wi-Fi is activated | |
| GPS signal is weak | Turning on the drone indoors | GPS signals cannot be found indoors. Please search for GPS signals in an open place outdoors |
| Under the tree, next to the building, in an obstructed place | Please stay away from obstacles for more than 32.81 feet(10 meters), and search for GPS signals in an open area | |
| Unable to return home, drifting and flying away | GPS signal was turned off during the flight | Please don't turn off GPS suddenly during outdoor flight. Switch back to GPS mode in time |
| The Transmitter does not charge / App always says the Transmitter has low battery | The phone cannot connect to the Transmitter due to the wrong sequence for turning equipment on | The correct sequence is: Turn the Aircraft on first, then turn on the Transmitter. Next push the left stick up and down to pair the Transmitter with the Aircraft. Connect your mobile device to Wi-Fi in the end |
| The Aircraft cannot be paired with the Transmitter | Pairing the Transmitter with the Aircraft without unlocking the Transmitter | Correct pairing steps: 1. Turn on the Aircraft. 2. Turn on the Transmitter: push the left joystick to 12 o'clock position, and then push it down to 6 o'clock position to unlock the Transmitter and pair it with the Aircraft. Lights of the Aircraft turn pink if the Transmitter is successfully paired with the Aircraft |
| Cannot charge battery/- Cannot fully charge battery | Using inferior charger or charging on the computer with unstable voltage output | Use a mobile USB charger that ensures constant stable voltage output(5V) and amperage output (2-3A) |
| Using inferior charging cables | Please use the original factory charging cable to charge | |
| Short battery life | Flying in windy weather | Flying in windy weather will accelerate power loss |
| Flying in cold weather | In low temperatures, the chemical reaction of the lithium battery is slowed down and the energy cannot be fully released | |
| The product has slight marks | We tested all Aircraft before shipping | In order to give you the best experience, we tested functions of all Aircraft before shipping. Therefore, it is inevitable that there will be slight traces. However, it can be guaranteed that all Aircraft are 100% brand new |
