Configuration
Configuring HPT102
Power supply requirements
Parameter
Protocol
Frequency
Output power
Modulation type
Link Rate
Link Space
Forward Error Correction Enable
Scrambling
6. When finished, click File Disconnect.
22
Table 2-1. Modem Parameters for the Radio Link Tab
Base Modem
Select the Simplex Transmitter
protocol
For both Base and Rover modems the protocol type must be the same.
Set the frequency in band 138-174 MHz with 6.25 kHz channel spacing.
For both Base and Rover modems the frequency must be the same.
Select the transmission power for
the radio modem.
Specifies a modulation scheme that will be used by your modem.
DQPSK is recommended.
For both Base and Rover modems the modulation type must be the same.
The link rate is selected automatically
For both Base and Rover modems the link space must be the same.
Enable
Figure 2-6. Radio Link tab
Rover Modem
Select the Simplex modem protocol
n/a
Enable
Enable
