1. Introduction

The ZEB Vision can be used with the ZEB Horizon system to capture 360° panoramic photography
for point cloud visualisation and colourisation. Data is captured as the user walks through the area
of interest. The ZEB Vision uses GeoSLAM's leading SLAM algorithm to automatically and
accurately position panoramic photos on a point cloud for an interactive viewing experience.
Provided the simple guidelines set out in this manual are adhered to, accurate 3D point clouds can
be generated in a fraction of the time taken with traditional terrestrial laser scanning methods.

2. List of Parts

The ZEB Vision includes the items listed below.
Part no.
K_GS_ZEB_VISION
© 2022 GeoSLAM Ltd
Description
ZEB Vision camera and mount
ZEB Vision ethernet cable
3mm HEX Key
ZEB Horizon Hard Case
Figure 2-1. ZEB Vision components.
