4. Appendix – Firmware Update Procedure
All files required for the update process are available to download from the GeoSLAM website:
•
https://geoslam.com/getting-started-zeb-vision
Download the update pack file to your PC and extract the ZIP file to a temporary directory.

4.1. Download Package

The update package contains all files necessary to update both the ZEB Horizon and ZEB Vision
plus a copy of the Control Tool software to apply the updates.
File Contents
\Vision V2 firmware update
\SHB_2_2_Gen 1 Datalogger
\SHB_2_2_Gen 2 Datalogger
DataloggerTools-3.3.0.zip
ZEB_Vision_2_1_0.7z
Extract the Control Tool software to a directory on the PC. No other files in the update package
are required to be uncompressed.
To start the Control Tool software:
1. Select -> DataLoggerControlTool.exe.

4.2. Updating Camera Firmware

To update the ZEB Vision firmware the following file is required:
•
ZEB_Vision_2_1_0.7z.
Do not uncompress the file.
1. Connect the ZEB Horizon scanner to the datalogger using the main cable and power on
the system as normal.
2. Connect the camera to a PC as outlined in the ZEB Vision User Guide.
3. Open -> GeoSLAM Control Tool (Figure 1).
© 2022 GeoSLAM Ltd
Firmware update files for 1
Firmware update files for 2
Control Tool software to apply the firmware updates.
Firmware update file for Vision camera.
Table 1. Update package contents.
Page 10
Description
generation data loggers.
st
generation data loggers.
nd
ZEB Vision User Guide
