Touch Screen Operation - FeiYu Tech SCORP Mini Instructions Manual

8.2 Touch screen operation

[1] Current battery level
Show the current battery level of gimbal.
[2] Camera connection
Icon appears after camera connect to the gimbal successfully. The icon
won't be shown if camera doesn't connect to gimbal.
[3] Bluetooth connection
Icon appears after Bluetooth is connecting. And the icon won't be shown
if Bluetooth disconnect.
[4] Motor power
Use auto tune to adjust the motor power automatically, or adjust motor
power for each axis manually.
[5] Follow speed
Users can select different gimbal follow speed profiles, or customize follow
speed.
[6] Follow mode
Select gimbal follow mode.
PF: Pan follow, only the pan axis follows the movement of user's
hand.
PTF: Pan and tilt follow, where both the pan and tilt axes follow the
movement of user's hand, but roll axis does not.
FPV: Pan, tilt and roll follow, where all 3 axes follow the movement of
user's hand.
[2][3]
[1]
[4]
Motor power Follow speed
[6]
PTF
Home page
- 20 -
[5]
[7]
Scenario
