Summary of Contents for Alcatel-Lucent Enterprise H6
-
Page 1: Table Of Contents
Home PBXware SERVERware TELCOware SIPmon SIPProt Desktop & Mobile UADs Appliances From Bicom Systems Wiki Contents 1 Introduction 2 Requirements 2.1 Identifying Phone Model 2.2 Phone Firmware 2.3 DHCP Server 2.4 PBXware Version 3 Installation 3.1 Power Adapter 3.2 Power over Ethernet (PoE) 3.3 Find the Phone's IP Address 3.4 Reset to Factory Settings 4 Registering Phone... -
Page 2: Requirements
This configuration guide is written as a general guide on how to configure the Alcatel-Lucent Enterprise H6 phone model to work with PBXware 6.5.1 Requirements Identifying Phone Model To start and successfully complete the registration of your Alcatel-Lucent Enterprise phone, you need to know which phone model to set up. -
Page 3: Pbxware Version
PBXware Version PBXware version 6.5.1 In order to find out the PBXware version: Log in to PBXware Navigate to Settings: About. On the top of About page, you may see a code similar to this one PBXware Edition: Multi- Tenant Release: 6.5.1.0 (41a4f0e6) Running: 16.16.1-gc-2e09fa3d, Proxy v6.5.1 (231c5f3), API: 6, libmemcached version: 1.0.18, where Release denotes the current... -
Page 4: Find The Phone's Ip Address
Do not unplug or remove power to the phone while it is updating firmware and configuration. Registering Phone This section describes how to identify the Alcatel-Lucent Enterprise phone model, requirements that must be met, and how to register the phone using manual configuration or auto- provisioning. - Page 5 UAD settings Navigate to Settings: UAD. Make sure Alcatel-Lucent Enterprise H6 UAD is enabled. To check the UAD status, click the Edit icon corresponding to your Alcatel-Lucent Enterprise phone. Make sure Status is set to Active, Auto provisioning is set to No, and DHCP is set to Yes.
- Page 6 Department to which Extension belongs. Example: Sales. Click the Save button. Registering a Phone This section describes how to register the Alcatel-Lucent Enterprise phone using Hostname or IP Address. Hostname or IP Address Log in to the phone's web administration interface Open a new browser window and enter your phone IP address in order to access the phone's web administration interface login screen.
-
Page 7: Auto Provisioning
Display Name Usually the same number as the Authentication User. Authentication Password The Secret of the Extension as received in the e-mail associated with this extension. Example: _%Z4M3*Ts9y7. A password is generated automatically for each newly created Extension. SIP Server Enter the Hostname or IP Address of PBXware. - Page 8 UAD settings Navigate to Settings: UAD. Make sure Alcatel-Lucent Enterprise H6 UAD is enabled. To check the UAD status, click the Edit icon corresponding to your Alcatel-Lucent Enterprise phone. Make sure Status is set to Active, Auto provisioning is set to Yes, and DHCP is set to Yes.
- Page 9 MAC address can be found at the back of the phone. Click Save. Registering a Phone This section describes how to register the Alcatel-Lucent Enterprise phone using TFTP, or HTTP & HTTPS. TFTP & HTTP & HTTPS Open a new browser window and enter your phone's IP address, e.g. http://192.168.1.22.
-
Page 10: Configure Blf
Configure BLF Extension Settings This section describes how to configure BLF (Busy Lamp Field) for Alcatel-Lucent Enterprise Log in to the PBXware's web administration interface. Open a new browser window and enter the IP address in order to access the PBXware's web... -
Page 11: Additional Configuration Template
If you want to include some additional UAD configuration for Alcatel-Lucent Enterprise H6, just add fields to User Agent General Auto Provisioning Template in Settings -> UAD -> Alcatel-Lucent Enterprise H6 menu, or add them directly to the Extension in the UAD Auto Provisioning Template section.
