Installing Front Right GPUs
1. Begin by removing power from the system. Next remove the top cover.
2. Identify the front right bracket and graphics cards as illustrated.
3. Remove the pre-installed tabs on the GPU cards.
4. Insert the GPU cards into the PCIe slot on the riser card.
5. Secure each card to the bracket using the screws that are included for this purpose.
Make sure the screws do not fall through the vent holes on the GPU cards.
6. Connect one 8-pin power cable to each GPU card. Zip-tie the power cables.
7. Carefully position each bracket in the chassis as illustrated, aligning the four mounting
holes in the top and side of each bracket with the corresponding mounting holes in the
chassis. Pay attention to the airflow arrows to install each card into the correct side of
the chassis
8. As you are positioning the GPU bracket, route the power cables towards the power
distribution board.
Caution: Watch out for interference between the GPU power cables and the power
distribution board as you are connecting the GPU power cables.
9. Press the area on bracket above the PCIe slot firmly to ensure a good connection
between the GPU card and the motherboard.
10. Secure the bracket to the chassis by using the screws provided.
11. After the GPU card is installed, connect the GPU power cable to the blue connectors
(CON555 and CON556) on the power distribution board.
