Dorel Asia Baby Relax DA6564-1 Instruction Booklet

Dorel Asia Baby Relax DA6564-1 Instruction Booklet

3-drawer dresser two tone finish white & grey
Hide thumbs

Advertisement

Quick Links

Download this manual
DOREL ASIA
Model No:
DA6564-1 (WHITE & GREY)
3-DRAWER DRESSER
UPC CODE:
TWO TONE FINISH
0-65857-16804-4
NOTE:
THIS INSTRUCTION BOOKLET
IMPORTANT
CONTAINS
SAFETY
INFORMATION. PLEASE READ AND
KEEP FOR FUTURE REFERENCE.
Lot number:
(TAKEN FROM CARTON)
_____________________________________
Date of purchase:
_______ / _______ / _______
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer service
department. We will replace the part FREE of charge.
Tel #: 1-800-295-1980
NEED HELP!
E-Mail: das@dorel.com
CALL US FOR ASSISTA
Fax #: 514-353-7819
1-800-295-1980
DO NOT RETURN PROD
E-MAIL:DAS@DOREL.C

Advertisement

loading
Need help?

Need help?

Do you have a question about the Baby Relax DA6564-1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dorel Asia Baby Relax DA6564-1

Summary of Contents for Dorel Asia Baby Relax DA6564-1

  • Page 1 DOREL ASIA Model No: DA6564-1 (WHITE & GREY) 3-DRAWER DRESSER UPC CODE: TWO TONE FINISH 0-65857-16804-4 NOTE: THIS INSTRUCTION BOOKLET IMPORTANT CONTAINS SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Lot number: (TAKEN FROM CARTON) _____________________________________ Date of purchase: _______ / _______ / _______ DO NOT RETURN PRODUCT TO THE STORE.

  • Page 2: Care And Cleaning

    Check bolts/screws periodically and tighten them if necessary. LIMITED WARRANTY Dorel Asia warrants its product to be free from defects in material and workmanship and agrees to remedy any such defect. This warranty covers 1 year from the date of original purchase.

  • Page 3: Hardware List

    3-DRAWER DRESSER DA6564-1 HARDWARE LIST Ø15 * 12 mm Ø7 * 36 mm Ø8 * 30 mm LARGE CAM LOCK LARGE CAM BOLT LARGE WOOD DOWEL 12 PCS 12 PCS 26 PCS Ø1/4" * 32 mm Ø16 * 1 mm Ø12 * 1.5 mm BOLT FLAT WASHER...

  • Page 4: Parts List

    3-DRAWER DRESSER DA6564-1 PARTS LIST LEFT SIDE FRAME RIGHT SIDE FRAME TOP PANEL (WITH A REVERSIBLE PANEL) (WITH A REVERSIBLE PANEL) 1 PC 1 PC 1 PC FRONT MIDDLE RAIL FRONT MIDDLE RAIL FRONT TOP RAIL (REVERSIBLE RAIL) (REVERSIBLE RAIL) 1 PC 2 PCS 1 PC...
  • Page 5 3-DRAWER DRESSER DA6564-1 PARTS LIST BACK PANEL TOP DRAWER FRONT BOTTOM DRAWER FRONT 1 PC PANEL -2 PCS PANEL -1 PC RIGHT DRAWER SIDE LEFT DRAWER SIDE DRAWER BOTTOM PANEL PANEL- 3 PCS PANEL - 3 PCS 3 PCS DRAWER SUPPORT RAIL DRAWER BACK PANEL 3 PCS 3 PCS...
  • Page 6 3-DRAWER DRESSER DA6564-1 NOTE: Side Frames (B & C) and front middle rails (E & F) are reversible and can be attached so that they are either grey or white. Choose your preferred look before beginning assembly. All white dresser Dresser with grey side panels Dresser with grey front rails Dresser with grey front rails...
  • Page 7 3-DRAWER DRESSER DA6564-1 STEP 1 Insert large wood dowels (3) and large cam bolts (2) into left side frame (B). Insert large cam locks (1) into front top rail (D) and front middle rail (F). Attach front rails (D, E, & F) to left side frame (B). Secure the rails by rotating large cam lock (1) 1/2 clockwise using a Phillips head screwdriver (not included).
  • Page 8 3-DRAWER DRESSER DA6564-1 STEP 2 Insert large wood dowels (3) into left side frame (B). Attach front bottom rail (G) to left side frame (B) using bolt (4), flat washer (5) and spring washer (6). Use an Allen Key (12) to tighten bolt (4).
  • Page 9 3-DRAWER DRESSER DA6564-1 STEP 3 Insert large cam bolts (2) and large wood dowels (3) into left side frame (B). Insert large cam locks (1) into back top rail (H) and back bottom rail (I). Attach back top rail (H) and back bottom rail (I) to left side frame (B). Secure the rails by rotating large cam lock (1) 1/2 clockwise using a Phillips head screwdriver (not included).
  • Page 10 3-DRAWER DRESSER DA6564-1 STEP 4 Insert large wood dowels (3) and large cam locks (1) into rails (D, E, F, G, H & I) as shown below. Insert large cam bolts (2) into right side frame (C). Attach right side frame (C) to the assembled unit and secure it by rotating large cam locks (1) 1/2 turn clockwise with a Phillips head screwdriver (not included).
  • Page 11 3-DRAWER DRESSER DA6564-1 STEP 5 NOTE: left side frame (B) and right side frame (C) have reversible panels that are white on one side and grey on the other. Before moving on to the next step, make sure the panels are inserted so that your preferred color will be visible once assembly is complete. Slide the panels out from the top of side frames (B &...
  • Page 12 3-DRAWER DRESSER DA6564-1 STEP 6 Insert large cam locks (1) into side rails (D & H) and large wood dowels (3) into side frames (B & C) as shown. Insert large cam bolts (2) into top panel (A). Attach top panel (A) to the assembled unit. Secure top panel (A) by rotating large cam locks (1) 1/2 turn clockwise using a Phillips head screwdriver (not included).
  • Page 13 3-DRAWER DRESSER DA6564-1 STEP 7 Attach back panel (J) to the unit using round head screws (7) and a Phillips head screwdriver (not included).
  • Page 14 3-DRAWER DRESSER DA6564-1 STEP 8 Insert small wood dowels (8) and small cam bolts (9) into top drawer front panels (K) and bottom drawer front panel (L). Insert small cam locks (10) into right drawer side panels (M) and left drawer side panels (N).
  • Page 15 3-DRAWER DRESSER DA6564-1 STEP 9 Slide drawer bottom panels (O) into the grooves of drawer side panels (M & N). Insert small cam locks (10) into drawer support rails (P). Insert small cam bolts (9) and small wood dowels (8) into top drawer front panels (K) and bottom drawer front panel (L).
  • Page 16 3-DRAWER DRESSER DA6564-1 STEP 10 Attach drawer back panels (Q) to drawer bodies using flat head screws (11) with a Phillips head screwdriver (not included). 15 PCS...
  • Page 17 3-DRAWER DRESSER DA6564-1 STEP 11 Insert all drawers into the dresser.
  • Page 18 Furniture Wall Safety Strap SAFETY WALL STRAP WALL ANCHOR MOUNTING BRACKET SHORT SCREW LONG SCREW 2 PCS 2 PCS 4 PCS 2 PCS 2 PCS TOOLS NECESSARY: RUBBER MALLET AND PHILLIPS SCREW DRIVER ARE NOT INCLUDED. NOTE: 3/8" DRILL BIT AND ELECTRIC DRILL ARE NOT PROVIDED. WARNING: WHEN UPRIGHT, IT IS POSSIBLE THAT THE FURNITURE MAY TIP OVER.
  • Page 19 3-DRAWER DRESSER DA6564-1 CAUTION: This unit is intended for use only with the products and/or maximum weights indicated. Use with other products and/or products heavier than the maximum weights indicated may result in instability or cause possible injury. MAXIMUM WEIGHT FOR TOP IS 25 LBS MAXIMUM WEIGHT FOR ALL DRAWERS...
  • Page 20 MODEL #: DA6564-1 Customer Service PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S). Customer Service Phone Number 1-800-295-1980 Email: das@dorel.com Customer Service Fax Number 514-353-7819 Request Date: Name: Shipping Address:...
