DOREL ASIA
SWIVEL GLIDER
CONTAINS
INFORMATION. PLEASE READ AND
KEEP FOR FUTURE REFERENCE.
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer service
department. We will replace the part FREE of charge.
DA6727SGT-BR (Brown)
DA6727SGT-BG (Beige)
DA6727SGT-GR (Grey)
0-65857-16687-3 (Brown)
0-65857-16688-0 (Beige)
0-65857-16689-7 (Grey)
THIS INSTRUCTION BOOKLET
IMPORTANT
(TAKEN FROM CARTON)
___________________
Date of purchase:
_______ / _______ / _______
Tel #: 1-800-295-1980
NEED HELP!
E-Mail: das@dorel.com
CALL US FOR ASSISTA
Fax #: 514-353-7819
1-800-295-1980
DO NOT RETURN PROD
E-MAIL:DAS@DOREL.C
Model No:
UPC CODE:
NOTE:
SAFETY
Lot number:
Advertisement
Table of Contents
Related Manuals for Dorel Asia Baby Relax DA6727SGT-BR
Summary of Contents for Dorel Asia Baby Relax DA6727SGT-BR
- Page 1 DOREL ASIA Model No: DA6727SGT-BR (Brown) DA6727SGT-BG (Beige) DA6727SGT-GR (Grey) UPC CODE: 0-65857-16687-3 (Brown) SWIVEL GLIDER 0-65857-16688-0 (Beige) 0-65857-16689-7 (Grey) NOTE: THIS INSTRUCTION BOOKLET IMPORTANT CONTAINS SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Lot number: (TAKEN FROM CARTON)
-
Page 2: Care And Cleaning
Check bolts/screws periodically and tighten them if necessary. LIMITED WARRANTY Dorel Asia warrants its product to be free from defects in material and workmanship and agrees to remedy any such defect. This warranty covers 1 year from the date of original purchase. This warranty is valid only upon presentation of proof of purchase. -
Page 3: Hardware List
SWIVEL GLIDER DA6727SGT-BR / DA6727SGT-BG / DA6727SGT-GR HARDWARE LIST Ø5/16" X 2-3/8" Ø22 X 1.8mm Ø12.5 X 1.5mm HEX SOCKET HEAD BOLT FLAT WASHER SPRING WASHER 7 PCS 7 PCS 7 PCS M5 X 64mm ALLEN KEY 1 PC PARTS LIST LEFT ARM RIGHT ARM CHAIR BACK... - Page 4 SWIVEL GLIDER DA6727SGT-BR / DA6727SGT-BG / DA6727SGT-GR STEP 1: Place all parts on a clean, smooth surface. Place the left arm (A) onto the seat base (D). Lift the side covers on the seat base (D) to secure the left arm (A) using flat washers (2), spring washers (3) and hex socket head bolts (1).
- Page 5 SWIVEL GLIDER DA6727SGT-BR / DA6727SGT-BG / DA6727SGT-GR STEP 2: Attach the chair back (C) to the assembled unit by inserting the metal brackets on chair back (C) into the metal glides on left arm (A) and right arm (B). Push the chair back (C) with a downward force to secure it into place.
- Page 6 SWIVEL GLIDER DA6727SGT-BR / DA6727SGT-BG / DA6727SGT-GR STEP 3: With the help of another person, gently place the unit on its side and lift the fabric flap underneath seat base (D). Secure chair back (C) to seat base (D) with flat washers (2), spring washers (3) and hex socket head bolts (1).
- Page 7 SWIVEL GLIDER DA6727SGT-BR / DA6727SGT-BG / DA6727SGT-GR STEP 4: Place seat cushion (E) on the glider.
- Page 8 SWIVEL GLIDER DA6727SGT-BR / DA6727SGT-BG / DA6727SGT-GR CAUTION: This unit is intended for use only with the products and/or maximum weights indicated. Use with other products and/or products heavier than the maximum weights indicated may result in instability or cause possible injury. Dust regularly with a soft, dry cloth to prevent soil build up.
- Page 9 MODEL #: DA6727SGT-BR / DA6727SGT-BG / DA6727SGT-GR Customer Service PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S). Customer Service Phone Number 1-800-295-1980 Email: das@dorel.com Customer Service Fax Number 514-353-7819 Request Date:...
