DOREL ASIA
3-PC PUB SET
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer service
department. We will replace the part FREE of charge.
0-65857-16632-3
THIS INSTRUCTION BOOKLET
CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND
KEEP FOR FUTURE REFERENCE.
(TAKEN FROM CARTON)
_________________________
Date of purchase:
_______ / _______ / _______
Tel #: 1-800-295-1980
NEED HELP!
E-Mail: das@dorel.com
CALL US FOR ASSI
1-800-295-1980
DO NOT RETURN P
E-MAIL:DAS@DOR
Model No:
DA6711
UPC CODE:
NOTE:
Lot number:
Fax #: 514-353-7819
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Dorel Asia DA6711
Summary of Contents for Dorel Asia DA6711
- Page 1 DOREL ASIA 3-PC PUB SET Model No: DA6711 UPC CODE: 0-65857-16632-3 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Lot number: (TAKEN FROM CARTON) _________________________ Date of purchase: _______ / _______ / _______ DO NOT RETURN PRODUCT TO THE STORE.
-
Page 2: Care And Cleaning
Check bolts/screws periodically and tighten them if necessary. LIMITED WARRANTY Dorel Asia warrants its product to be free from defects in material and workmanship and agrees to remedy any such defect. This warranty covers 1 year from the date of original purchase. This warranty is valid only upon presentation of proof of purchase. -
Page 3: Hardware List
3-PC PUB SET DA6711 HARDWARE LIST Ø1/4" X 2-3/4" Ø8 X 30mm BARREL NUT BOLT WOOD DOWEL 4 PCS 4 PCS 2 PCS Ø5/32" X 1-1/2" Ø1/4" X 2" WOOD SCREW BOLT SPRING WASHER 20 PCS 24 PCS 24 PCS... -
Page 4: Parts List
3-PC PUB SET DA6711 PARTS LIST RIGHT BACK POST LEFT BACK POST LEFT FRONT POST 1 PC 1 PC 1 PC RIGHT FRONT POST BACK STRETCHER SIDE STRETCHER 1 PC 1 PC 2 PCS TABLE TOP STOOL LEG STOOL LEG... - Page 5 3-PC PUB SET DA6711 STEP 1 Insert wood dowels (3) and barrel nuts (1) into back stretcher (E) as shown below. Attach right back post (A) and left back post (B) to back stretcher (E) with bolts (2) using Allen key (8).
- Page 6 3-PC PUB SET DA6711 STEP 2 Place table top (G) upside down on a clean, smooth surface. Attach side stretchers (F) to the posts (A, B, C & D) with wood screws (4) using a Phillips head screwdriver (not included).
- Page 7 3-PC PUB SET DA6711 STEP 3 Insert barrel nuts (1) into the table apron as shown. Secure front posts (D & C) to table top (G) using bolts (2) and Allen Key (8). Turn the table upright.
- Page 8 3-PC PUB SET DA6711 STEP 4 Connect side stretcher (J) to stool legs (H & I) with wood screws (4). Use a Phillips head screwdriver to tighten the screws.
- Page 9 3-PC PUB SET DA6711 STEP 5 Place seat cushion (K) on a clean, smooth surface. Attach stretchers (J) to the assembled legs (H & I) with wood screws (4) using a Phillips head screwdriver (not included). Attach the stool legs (H & I) to the seat cushion (K) with spring washers (7), flat washers (6) and bolts (5) using Allen key (8).
- Page 10 3-PC PUB SET DA6711 CAUTION: This unit is intended for use only with the products and/or maximum weights indicated. Use with other products and/or products heavier than the maximum weights indicated may result in instability or cause possible injury. Product...
- Page 11 MODEL #: DA6711 Customer Service PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S). Customer Service Phone Number 1-800-295-1980 Email: das@dorel.com Customer Service Fax Number 514-353-7819...
