INSTRUCTION MANUAL
CLUB CHAIR
CONTAINS
INFORMATION. PLEASE READ AND
KEEP FOR FUTURE REFERENCE.
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer service
department. We will replace the part FREE of charge.
0-65857-16506-7
0-65857-16932-4
THIS INSTRUCTION BOOKLET
IMPORTANT
(TAKEN FROM CARTON)
___________________
Date of purchase:
_______ / _______ / _______
Tel #: 1-800-295-1980
E-Mail: das@dorel.com
NEED HELP!
CALL US FOR ASSISTANCE
Fax #: 514-353-7819
1-800-295-1980
DO NOT RETURN PRODUC
E-MAIL:DAS@DOREL.COM
Model No.:
DA6542F1
DA6542F-BG
UPC CODE:
NOTE:
SAFETY
Lot number:
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Dorel Asia CLUB CHAIR DA6542F1
Summary of Contents for Dorel Asia CLUB CHAIR DA6542F1
- Page 1 INSTRUCTION MANUAL Model No.: CLUB CHAIR DA6542F1 DA6542F-BG UPC CODE: 0-65857-16506-7 0-65857-16932-4 NOTE: THIS INSTRUCTION BOOKLET IMPORTANT CONTAINS SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Lot number: (TAKEN FROM CARTON) ___________________ Date of purchase: _______ / _______ / _______ DO NOT RETURN PRODUCT TO THE STORE.
-
Page 2: Care And Cleaning
Check bolts/screws periodically and tighten them if necessary. LIMITED WARRANTY Dorel Asia warrants its product to be free from defects in material and workmanship and agrees to remedy any such defect. This warranty covers 1 year from the date of original purchase. This warranty is valid only upon presentation of proof of purchase. -
Page 3: Hardware List
CLUB CHAIR DA6542F1 / DA6542F-BG HARDWARE LIST Ø5/16" X 63mm Ø22 X 1.8mm Ø12.5 X 1.2mm HEX SOCKET HEAD BOLT FLAT WASHER SPRING WASHER 3 PCS 3 PCS 3 PCS Ø5/16" X 90mm Ø19 X 1.0mm HEX SOCKET HEAD BOLT FLAT WASHER ALLEN KEY 4 PCS... -
Page 4: Parts List
CLUB CHAIR DA6542F1 / DA6542F-BG PARTS LIST CHAIR BACK CHAIR BODY FOOT 1 PC 1 PC 4 PCS SEAT CUSHION 1 PC... - Page 5 CLUB CHAIR DA6542F1 / DA6542F-BG STEP 1: Attach chair back (A) to chair body (B) by inserting the metal brackets on chair back (A) into the metal glides on chair body (B). Push the chair back (A) with a downward force to secure it into place. Note: Make sure that the back of chair back (A) is flush with the back of the chair arms when attaching the chair back (A) to the chair body (B).
- Page 6 CLUB CHAIR DA6542F1 / DA6542F-BG STEP 2: With the help of another person, gently turn the unit upside down and pull back the fabric lining underneath chair body (B). Secure chair back (A) to chair body (B) with flat washers (2), spring washers (3) and hex socket head bolts (1).
- Page 7 CLUB CHAIR DA6542F1 / DA6542F-BG STEP 3: Attach feet (C) to chair body (B) with flat washers (5) and hex socket head bolts (4). Use Allen Key (6) to tighten the bolts. Turn the chair upright.
- Page 8 CLUB CHAIR DA6542F1 / DA6542F-BG STEP 4: Place the seat cushion (D) onto the chair body (B).
- Page 9 CLUB CHAIR DA6542F1 / DA6542F-BG CAUTION: This unit is intended for use only with the products and/or maximum weights indicated. Use with other products and/or products heavier than the maximum weights indicated may result in instability or cause possible injury. Dust regularly with a soft, dry cloth to prevent soil build up.
- Page 10 MODEL #: DA6542F1 & DA6542F-BG Customer Service PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S). Customer Service Phone Number 1-800-295-1980 Email: das@dorel.com Customer Service Fax Number 514-353-7819 Request Date: Name:...
