Argos Franklin Recliner 2493567 Assembly Instructions

Components
01
X Back cushion
( 02)
X Seat
(03)
X Arm-pad
Fittings
A D D
(8X25)
X2
B E E
(6X40)
X10
C F F
(8X70)
X2
(04) X Ottoman seat cushion
(05)
(06)
X Wood brace
(07)
X Hand wheel
X2 X2
(M8)
(8X45) (8X45)
X4 X4
(M6)
(8*22*2mm) (8*22*2mm)
X4 X4
Franklin Recliner Chair And Foot stool
Simple Assembly Instructions
X Wood base
1.Read these instruction carefully and
familiarise yourself with the procedure
before assembling the unit.
2.Check that you have all the component
parts following the list on the back
cover and familiarise yourself with
each part before proceeding.
-
Please keep for future refence
0345 640 0800
3.Take all the fittings out of the plastic
bag and separate them into their groups.
4.Ensure you have enough space to lay
out all the parts before assembly.
5.To avoid scratching it is recommended
that you assemble the unit on a soft
level surface.
2493567
2448172
