Newport - Chest Pack
Assembly Instructions -
2 Drawer Chest
Dimensions
Width - 65.5cm
Depth - 35.5cm
Height - 57.5cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
Bedside Chest
Dimensions
Width - 35.5cm
Depth - 35.5cm
Height - 41cm
245/8409
249/3842
MADE IN
BRITAIN
Issue 1 - 22/05/14
Advertisement
Related Manuals for Argos Newport Chest Pack
Summary of Contents for Argos Newport Chest Pack
- Page 1 Newport - Chest Pack Assembly Instructions - 245/8409 Please keep for future reference 249/3842 2 Drawer Chest Bedside Chest Dimensions Dimensions Width - 65.5cm Width - 35.5cm Depth - 35.5cm Depth - 35.5cm MADE IN Height - 57.5cm Height - 41cm BRITAIN Important - Please read these instructions fully before starting assembly...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 22.5kgs. space to layout the parts before recommend the Please lift with care. starting.
- Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below Bedside Chest Panels Left End Right End Fixed Shelf (DF272) (DF273) (DF274) (DF275)
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Steps 1-20 will show you how to build the Bedside Chest Prepare the small drawer front Screw 2 metal dowels into the small drawer front Note: Tighten the metal...
- Page 6 Assembly Instructions Step 4 Fit the small drawer base Slide the small drawer base down the grooves in the drawer sides down into the groove in the small drawer front Step 5 Fit the small drawer back Fit the small drawer back between the drawer sides Make sure that the small...
- Page 7 Assembly Instructions Step 7 Attach the handle Attach a handle to the small drawer front using screw Note: Do not overtighten the screws. Step 8 Fit the wedgefixes Turn the drawer assemblies over and slide 2 wedgefixes into the front and back grooves, as shown, and tighten up the screws.
- Page 8 Assembly Instructions Step 10 Prepare the fixed shelf Insert 4 large locking nuts into the fixed shelf Finished front edge Step 11 Fit the fixed shelf to the right end Push the fixed shelf onto the right end Use a screwdriver to tighten the 2 large locking nuts fitted to...
- Page 9 Assembly Instructions Step 13 Fit the plinth Push the plinth onto the right end Use a screwdriver to tighten the large locking fitted to the plinth Step 14 Finished Prepare the left end front edge Push fit a left runner marked ‘L’...
- Page 10 Assembly Instructions Step 16 Prepare the top Screw 2 metal dowels into the top Finished front edge Step 17 Fit the top Push the top onto the assembly. Use a screwdriver to tighten the 4 large locking nuts fitted to the left end and right Step 18...
- Page 11 Assembly Instructions Step 19 The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Fit the back Square up the unit by making sure that measurement x to x equals y to y.
- Page 12 Assembly Instructions Step 21 Steps 21-41 will show you how to build the 2 Drawer Chest Prepare the 2 large drawer fronts Screw 2 metal dowels into each large drawer front Note: Tighten the metal dowels up fully against the panels. Step 22 Prepare 2 pairs of drawer sides...
- Page 13 Assembly Instructions Step 24 Fit the large drawer base Slide the large drawer base down the grooves in the drawer sides down into the groove in the large drawer front Step 25 Fit the large drawer back Fit the large drawer back between the drawer sides Make sure that the large...
- Page 14 Assembly Instructions Step 27 Attach the handles Attach 2 handles each large drawer front using screws Note: Do not overtighten the screws. Step 28 Fit the wedgefixes Turn the drawer assemblies over and slide 2 wedgefixes into the front and back grooves, as shown, and tighten up the screws.
- Page 15 Assembly Instructions Step 30 Prepare the fixed shelf Insert 4 large locking nuts into the fixed shelf Finished front edge Step 31 Fit the fixed shelf to the right end Push the fixed shelf onto the right end Use a screwdriver to tighten the 2 large locking nuts fitted to...
- Page 16 Assembly Instructions Step 33 Prepare the 2 plinths Tap 2 wooden dowels into each plinth Insert 2 large locking nuts into each plinth Step 34 Fit the 2 plinths Push the 2 plinths onto the right end Use a screwdriver to tighten the large locking fitted to each of the plinths...
- Page 17 Assembly Instructions Step 36 Prepare the top Screw 4 metal dowels into the top Finished front edge Step 37 Fit the top Push the top onto the assembly. Use a screwdriver to tighten the 4 large locking nuts fitted to the left end and right Step 38...
- Page 18 The chest assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW...
- Page 20 ALR3053...
