Designer 2 Tone - TV Unit

Assembly Instructions -

Dimensions

Width - 113.5cm

Depth - 40cm

Height - 61cm

Important -

Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800

Please keep for future reference

249/8593

MADE IN

BRITAIN

Issue 2 - 02/07/14

Need help?

Do you have a question about the Designer 2 Tone and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos Designer 2 Tone

Page 1 Designer 2 Tone - TV Unit Assembly Instructions - 249/8593 Please keep for future reference Dimensions Width - 113.5cm Depth - 40cm MADE IN Height - 61cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800...
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 29.5kgs. space to layout the parts before recommend the Please lift with care. starting.
Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below Flyover Top (D2969A) (D2968A) (900 x 396mm) (900 x 396mm) 4 Left Upright Left Side Right Upright...
Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the 2 drawer fronts Screw 2 metal dowels into each of the drawer fronts Note: Tighten the metal dowels up fully against the panels.
Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the drawer sides and down into the groove in the drawer front Step 5 Fit the drawer back Fit the drawer back between the drawer sides Make sure that the drawer base...
Page 7 Assembly Instructions Step 8 Prepare the top Screw 6 metal dowels into the top Finished front edge Step 9 Insert 2 large locking nuts into the right upright Note: The arrow on the locking nut must point towards the hole in the edge of the panel.
Page 8 Assembly Instructions Step 11 Prepare the left upright Note: Do not use the through holes to fit the runners. Place 2 runners the left upright shown. Slide back the Finished top of runner and use the front edge 2nd hole from the front to fit the 1st screw Slide the runner back the other way and...
Page 9 Assembly Instructions Step 13 Prepare the left side Place 2 runners the left side shown. Slide back the Finished top of runner and use the front edge 2nd hole from the front to fit the 1st screw Slide the runner back the other way and fit the 2nd screw into...
Page 10 Assembly Instructions Step 15 Prepare the base Screw the 5 feet onto the base using screws Finished front edge Step 16 Fit the base Attach the base p l a i n c the assembly using 6 h i p screws a r d s u r...
Page 11 Assembly Instructions Step 17 The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Fit the back Square up the unit by Note: making sure that This gap is for measurement x to x cable management.
Page 12 Assembly Instructions Step 19 Secure the right side Attach the right side to the base using 2 screws Carefully stand the unit up for the next step. Warning: The unit is heavy. Lift with care. Step 20 Prepare the small upright Insert 2 large locking nuts...
Page 13 Assembly Instructions Step 22 Fit the small upright to the flyover top Position the small upright so that the screws from the mini blocks are over the holes in the Finished flyover top . front edge Tighten up the screws in the 2 mini blocks into the holes in the flyover-...
Page 14 Assembly Instructions Step 24 Fit the flyover top assembly Lower the flyover top and small upright down onto the unit as shown. Use a screwdriver to tighten the 4 large Finished locking nuts fitted to front edge the right side small upright Step 25 Fit the fixed shelf...
Page 15 Assembly Instructions Step 26 Fit the shelf studs For each of the 2 loose shelves , insert 4 shelf studs Step 27 Fit the loose shelves Lower the 2 loose shelves down onto the shelf studs...
Page 16 Assembly is complete hole If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR3049...
