CONTENTS:
A
x1
INSTALLATION:
1. Setting Up Clamp to VESA Gooseneck :
A
B
1A. Align VESA Gooseneck (A) with screw on clamp (B) and turn it in
clock-wise as shown. **Use Top screw for horizontal surfaces and side screw for
vertical surfaces.
Heavy-Duty Security
Gooseneck Clamp Stand
PAD-HGTSB
INSTRUCTION - MANUAL
B
x1
E
x4
Washer
C
x1
F
x1
M5 Allen Key
2. Attaching Enclosure to VESA
C
A
2A. Align holder VESA holes (C) to VESA plate holes (A). Insert washers
and screws (E, D) and turn it in clock-wise into threaded holes in holder
using provide tool (F) until securely tightened. Shown above.
888-733-4448
D
x4
M4 x 8
G
x1
F
E
D
X4
X4
