Connection to Flow EZ

For connection of FLOW UNIT to Flow EZ
cable from the FLOW UNIT to the Flow EZ
1
1 FLOW UNIT 2
(sensor)
For more information about how to connect and use the Flow EZ
check our webpage and Flow EZ
https://www.fluigent.com/research/instruments/pressure-flow-
controllers/lineup-series/flow-ez/
Once connected to the Flow EZ
and chip) flow rate can be measured either directly on the Flow EZ
in local mode or by using OxyGEN.
14
SETTING UP
TM
TM simply connect the USB
TM .
FLOW EZ
TM
(Pressure-based flow controller)
TM user manual:
and to the fluidic system (reservoir
TM
SETTING UP

Local mode:

Flow-rate measure
Once a FLOW UNIT is connected, the device automatically detects
it and the "Operation window" will display an additional zone
including the flow rate measurement.
2
The measured flow rate (Qmeas) is only monitoring purposes. To
directly control the flow rate, see next page (Flow rate control)
TM
In this configuration you will
have access to the measure
TM
of the flow rate in real time.
You can then adjust the
pressure to reach the flow
rate you want to target.
measure and control the flow-rate
1
Qmeas H20
87.00
2
+
M
Pmeas
432.0
Pcmd
432.0
Set Q Ctrl
3
1 Liquid type H2O or
Isopropanol
2 Range of the FLOW UNIT
depending on the target flow rate
(XS, S, M+, L+)
3 Switch to flow rate control
mode
see next page
4 Measured flow rate units
can be changed using the menu
5 Pressure command
set by the user
4
µL/min
mbar
4
mbar
Menu
to be
15
