Emerson PACSystems RX3i PROFINET Scanner Important Product Information page 16

GFK-2738AB
Catalog Number Module Description
IC694MDL753 32 Circuit Output 12/24 Vdc 0.5A Positive
IC694MDL754 32 Circuit Output with ESCP
IC694MDL758
32 Circuit Output 12/24 Vdc 0.5A Positive with ESCP
IC694MDL916 16 Circuit Output 4A Relay
IC694MDL930 8 Circuit Output 4A Relay Isolated
IC694MDL931 8 Circuit Output Relay Form BC Isolated
IC694MDL940 16 Circuit Output 2A Relay
IC695MDL765 16 Circuit Smart Output 24/125 Vdc 2A Positive Logic
IC693MAR590 8 Circuit Mixed 120 Vac Input / Relay Output
IC693MDR390 8 Circuit Mixed 24 Vdc Input / Relay Output
IC694MDR390 8 Circuit Mixed 24 VDC Input / Relay Output
IC693ALG220 4 Point Analog Voltage Input
IC693ALG221 4 Point Analog Current Input
IC693ALG222 16 Point Analog Voltage Input
IC693ALG223 16 Point Analog Current Input
IC694ALG220 4 Point Analog Voltage Input
IC694ALG221 4 Point Analog Current Input
IC694ALG222 16 Point Analog Voltage Input
IC694ALG223 16 Point Analog Current Input
IC695ALG106 6 Point Isolated Analog Input Current/Voltage
IC695ALG112 12 Point Isolated Analog Current/Voltage Input
IC695ALG600 8 Point Universal Analog Input Module
IC695ALG608 8 Point Analog Input Current / Voltage Input
IC695ALG616 16 Point Analog Current / Voltage Input
IC695ALG626 16 Point Analog Current / Voltage Input
IC695ALG628 8 Point Analog Current / Voltage Input
IC693ALG390 2 Point Analog Voltage Output
IC693ALG391 2 Point Analog Current Output
IC693ALG392 8 Point Analog Current / Voltage Output
IC694ALG390 2 Point Analog Voltage Output
IC694ALG391 2 Point Analog Current Output
IC694ALG392 8 Point Analog Current / Voltage Output
IC695ALG704 4 Point Analog Current / Voltage Output
IC695ALG708 8 Point Analog Current / Voltage Output
IC695ALG728 8 Point Analog Current / Voltage Output
IC695ALG808 8 Point Isolated Analog Current / Voltage Output
IC693ALG442 4 Input / 2 Output, Current / Voltage
IC694ALG442 4 Input / 2 Output, Current / Voltage
5 PNS currently does not support Fault Reporting or Interrupts from this module. Also, only Type A and Type B counters are supported.
6 PNS firmware version 2.30 or later supports the HART
HART Device Information COMMREQ support only (no HART variables in IO Data). HART-compatible CPU and PNC001 versions are required.
Discrete Mixed Modules
Analog Input Modules
5
5
5
5
5
5 (HART 6 Support)
5 4
(HART Support)
Analog Output Modules
5
5
5 (HART 6
5
Analog Mixed Modules
® Pass Through capabilities of this module. PNS firmware version 2.41 or later supports Remote Get
2
4
Support)
Jul 2022
Distinguishing Classes 3
32 out
none
none
none
8 out
8 out
16 out
None
8 in/out
8 in/out
8 in/out
ALG IN 4
ALG IN 4
ALG IN 16
ALG IN 16
ALG IN 4
ALG IN 4
ALG IN 16
ALG IN 16
none
none
none
none
none
none
none
ALG OUT 2
ALG OUT 2
ALG OUT 8
ALG OUT 2
ALG OUT 2
ALG OUT 8
none
none
none
none
ALG IN 4, ALG OUT 2
ALG IN 4, ALG OUT 2
14
