100 Speed LED
Green, on
Green, blinking
Off
10 Speed LED
Green, on
Green, blinking
Off
ACTIVE LED
The active LED indicates the Scanner is connected to a PROFINET I/O Controller that is controlling the I/O data for the
PNS's I/O modules.
Green, on
Off
Front Panel LNK LED
The Front Panel LNK LED indicates the link established on the front Ethernet port.
Green, on
Off
Front Panel ACT LED
The front panel ACT LED indicates activity on the front Ethernet port when blinking.
Amber, blinking
Amber, On
Off
Link connected, 100 Mbps.
Port active, 100 Mbps
The associated Ethernet port is not connected to an active link at 100Mbps
Link connected, 10 Mbps.
Port active, 10 Mbps
The associated Ethernet port is not connected to an active link at 10Mbps
PNS is connected to a PROFINET I/O Controller that is controlling I/O Module IO data.
PNS is not connected to a PROFINET I/O Controller.
Ethernet link established.
No Ethernet link
Activity on front panel Ethernet port.
No activity on the front Ethernet port, but the link is connected
No link is connected.
