6 / 0 5
Table 1: Thermocouple input ranges
Type
Temperature range
mV
B
E
J
K
N
R
S
T
Analog Outputs
Number of outputs
Output range
Resolution
Conversion time
Load impedance
Galvanic isolation
Analog outputs to bus
Analog outputs to
Analog/PT/TC inputs
Analog outputs to analog
outputs
Linearity error
Operational error limits
Notes:
13. Note that the range of each I/O is defined by wiring, jumper settings, and within the controller's
software.
Environmental
Operating temperature
Storage temperature
Relative Humidity (RH)
Dimensions (WxHxD)
Weight
Unitronics
ANSI (USA)
-5 to 56mV
-
+Grey
200 to 1820°C
(300 to 3276°F)
-Red
+Violet
-200 to 750°C
(-328 to 1382°F)
-Red
+White
-200 to 760°C
(-328 to 1400°F)
-Red
+Yellow
-200 to 1250°C
(-328 to 2282°F)
-Red
+Orange
-200 to 1300°C
(-328 to 2372°F)
-Red
+Black
0 to 1768°C
(32 to 3214°F)
-Red
+Black
0 to 1768°C
(32 to 3214°F)
-Red
+Blue
-200 to 400°C
(-328 to 752°F)
-Red
4 (single-ended)
0-10V, 4-20mA. See Note 13.
12-bit (4096 units)
Synchronized to scan time.
1kΩ minimum—voltage
500Ω maximum—current
Yes
Yes
No
±0.1%
±0.2%
IP20 / NEMA1
0° to 45°C (32° to 113°F)
-20° to 60°C (-4° to 140°F)
5% to 90% (non-condensing)
138x23x123mm (5.43x0.9x4.84")
262g (9.25 oz)
V 2 0 0 - 1 8 - E 4 X B
Wire Color
BS 1843 (UK)
-
+None
-Blue
+Brown
-Blue
+Yellow
-Blue
+Brown
-Blue
+Orange
-Blue
+White
-Blue
+White
-Blue
+White
-Blue
S n a p - i n I / O M o d u l e
15
