V 2 0 0 - 1 8 - E 4 X B
Transistor Outputs
Number of outputs
Output type
Outputs #0 and #1
Outputs #2 to #16
Galvanic isolation
Transistor outputs to bus
Transistor outputs to
transistor outputs
Group to group
Output current
Maximum frequency
High-speed output maximum
frequency (resistive load).
See Note 6
ON voltage drop
Short circuit protection
pnp (source) power supply
npn (sink) power supply
operating voltage
Notes:
5. Outputs #0, 1, 2, 3, 4, 5, 6, 7 and 8 share a common power signal. Outputs
#8,9,10,11,12,13,14,15 and 16 share a common power signal. All outputs share a common 0V
signal.
6. Output #0 and 1 may be used as high-speed outputs.
Analog I/O's Power Supply
Nominal operating voltage
Operating voltage
Quiescent current
Max. current consumption
Galvanic isolation
Analog power supply to bus
Analog power supply to
analog inputs
Analog power supply to
analog outputs
12
S n a p - i n I / O M o d u l e
17 (in two groups). See Note 5.
pnp: P-MOSFET (open drain)
npn: N-MOSFET (open drain)
Each can be individually set as pnp (source) or npn (sink) via wiring and
jumper settings
pnp: P-MOSFET (open drain)
Yes
No
No
pnp: 0.5A maximum per output, total maximum current for each group: 3A.
npn: 50mA maximum per output
Resistive load
20Hz
Inductive load
0.5Hz
pnp: 2kHz
npn: 50kHz
pnp: 0.5VDC maximum
npn: 0.4VDC maximum
Yes (pnp only)
See Digital Output's Power Supply above
3.5V to 28.8VDC,
unrelated to the voltage of either the I/O module or the controller
24VDC
20.4 to 28.8VDC
70mA@24VDC
130mA@24VDC
Yes
Yes
Yes
6 / 0 5
