V200-18-E5B
The V200-18-E5B
plugs directly into the
back of compatible
Unitronics OPLCs,
creating a self-
contained PLC unit
with a local I/O
configuration.
Before using this product, it is the responsibility of the user to read and understand this document
and any accompanying documentation.
All examples and diagrams shown herein are intended to aid understanding, and do not guarantee
operation. Unitronics accepts no responsibility for actual use of this product based on these
examples.
Please dispose of this product in accordance with local and national standards and regulations.
Only qualified service personnel should open this device or carry out repairs.
User safety and equipment protection guidelines
This document is intended to aid trained and competent personnel in the installation of this equipment as
defined by the European directives for machinery, low voltage, and EMC. Only a technician or engineer trained
in the local and national electrical standards should perform tasks associated with the device's electrical wiring.
Symbols are used to highlight
information relating to the user's
personal safety and equipment
protection throughout this document.
When these symbols appear, the
associated information must be read
carefully and understood fully.
Caution
Environmental Considerations
Unitronics
Snap-in I/O Module
Features
18 isolated digital inputs, includes 2 H.S.C inputs, type pnp/npn
(source/sink)
15 isolated pnp (source) outputs
2 isolated pnp/npn (source/sink) transistor outputs, includes 2 H.S. outputs
3 analog inputs
Symbol
Caution
Failure to comply with appropriate safety guidelines can result in severe personal
injury or property damage. Always exercise proper caution when working with
electrical equipment.
Check the user program before running it.
Do not attempt to use this device with parameters that exceed permissible levels.
Install an external circuit breaker and take appropriate safety measures against short-
circuiting in external wiring.
To avoid damaging the system, do not connect / disconnect the device when the
power is on.
Ascertain that terminal blocks are properly secured in place.
Do not install in areas with: excessive or conductive dust, corrosive or flammable gas,
moisture or rain, excessive heat, regular impact shocks or excessive vibration.
Provide proper ventilation by leaving at least 10mm of space between the top and
bottom edges of the device and the enclosure walls.
Do not place in water or let water leak onto the unit.
Do not allow debris to fall inside the unit during installation.
Meaning
Description
The identified danger causes physical
Danger
and property damage.
The identified danger can cause
Warning
physical and property damage.
Caution
Use caution.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V200-18-E5B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Unitronics V200-18-E5B

  • Page 1 All examples and diagrams shown herein are intended to aid understanding, and do not guarantee operation. Unitronics accepts no responsibility for actual use of this product based on these examples. Please dispose of this product in accordance with local and national standards and regulations.
  • Page 2: Wiring Procedures

    Inputs I0 and I2 can be used as normal digital inputs, as high-speed counters, or as part of a shaft encoder. Inputs I1 and I3 can be used as normal digital inputs, as high-speed counter resets, or as part of a shaft encoder. Unitronics...
  • Page 3 (sink) digital input wiring pnp (source) digital input wiring npn (sink) high-speed counter pnp (source) high-speed counter Inputs I0, I1, and I2, I3 can be used as shaft encoders as shown below. npn (sink) shaft encoder wiring pnp (source) shaft encoder wiring Unitronics...
  • Page 4: Transistor Outputs

    6. Outputs 2 to 16 function as pnp only. The 0V signal of the transistor outputs is isolated from the controller’s 0V signal. npn (sink) pnp (source) Unitronics...
  • Page 5: Analog Inputs

    - Use the appropriate wiring as shown below. - Open the device and set the jumpers according to the instructions beginning on page 6. Inputs may be wired to work with either current or voltage. All inputs share a common COM signal. current current/voltage Unitronics...
  • Page 6: Changing Jumper Settings

    3. Using a Philips screwdriver, remove the center screw, shown in the figure below, from the module’s upper PCB board. Do not remove any other screws. 4. Holding the PCB board by its edges, gently lift it out of the module. Unitronics...
  • Page 7 Analog input 2 Analog input 1 Analog input 0 Digital Output Jumpers Jumper # PNP* Note that Jumpers #5, 8, 11, 12, 13, 14, 15 & 16 Digital Output 0 are not used Digital Output 1 * Default factory setting Unitronics...
  • Page 8 Next, reinstall the module. Line the circular guidelines on the controller up with the guidelines on the Snap-in I/O Module as shown below. Apply even pressure on all 4 corners until you hear a distinct ‘click’. The module is now installed. Check that all sides and corners are correctly aligned. Unitronics...
  • Page 9 Automation Ltd - 01480 395256 3/05 V200- 18- E5B S n a p - i n I / O M o d u l e V200-18-E5B Technical Specifications Digital Inputs Number of inputs 18 (in two groups) Input type...
  • Page 10 Outputs #0, 1, 2, 3, 4, 5, 6, 7 and 8 share a common power signal. Outputs #8,9,10,11,12,13,14,15 and 16 share a common power signal. All outputs share a common 0V signal. Output #0 and 1 may be used as high-speed outputs. Unitronics...
  • Page 11 Linearity error ±2 LSB (0.2%) Environmental IP20 / NEMA1 Operating temperature 0° to 45°C (32° to 113°F) Storage temperature -20° to 60°C (-4° to 140°F) Relative Humidity (RH) 5% to 90% (non-condensing) Dimensions (WxHxD) 138x23x123mm (5.43x0.9x4.84”) Weight 186.3g (6.57 oz) Unitronics...
