TIB SERIES
Battery Operated Paddle Wheel Flow Meter
Dimensions
V Series
TIB Series
3.96 in
[100.7 mm]
H Series
2.54 in
[64.5 mm]
3.62 in
[91.9 mm]
4.36 in
[110.7 mm]
2.66 in
[67.5 mm]
TIB Series
4.96 in
[126.1 mm]
3.90 in
[99.1 mm]
3.62 in
[91.9 mm]
4.36 in
[110.7 mm]
2.66 in
[67.5 mm]
TIB Series
4.96 in
[126.1 mm]
2.68 in
[68.0 mm]
