CAL-ROYAL PRODUCTS
8600 AUTOMATIC SWING DOOR OPERATOR
Operations & Installation Manual
CAL-ROYAL
These installation instructions detailed within are solely for professional installers
and are not intended to be handed over to the end user.
Ver. September 30, 2021
CAL-ROYAL PRODUCT INC.
#6605 Flotilla St. Commerce
CA, 90040, USA
Tel: (323) 888-6601, Fax: (323) 888-6699
Web:
www.cal-royal.com
Email:
mailto:sales@cal-royal.com
1
