Fountain Components
Item Description
Facet Fountain
- Disc
Facet Fountain -
Small Pedestal
Facet Fountain -
Small Bowl
Facet Fountain -
Pump House
Facet Fountain
- Pump House
Door
Facet Fountain -
Large Bowl
Fountain Information:
• Two people are recommended for the installation of this fountain!
• This fountain holds approximately 10-15 gallons of water.
• This fountain uses a medium fountain cover: FTNCOV-MED
• Compatible with #10 Refill Device
• A different style stopper may be requested for the refill kit.
Pump Information:
OEMPF525 - 525 GPH Pump (16 ft. cord length)
Tools Required:
Bubble Level
Screwdriver
Component
Quantity
Item #
FT-347A
1
FT-347B
1
FT-347C
1
FT-347D
1
FT-347E
1
FT-347F
1
FT-347 Facet Fountain
Assembly Instructions
Pump Kit Parts List
Component
PK500 Pump
(use adapter indicated)
#10 Stopper
6 1/2" length of 1" ID copper pipe
Approx. 12" length of 1/2" black
non-kink tubing
Approx. 2" length of 5/8" clear tubing
Approx. 2" length of 1/2" CPVC pipe
Copper Spillers
(FT-347SPL)
2.8 oz clear silicone
Hose Clamps
Proudly
MADE IN USA
Quantity
1
1
1
1
1
1
Wedges
3
4
1
1
rev 9/28/2020
