L A
OOP TTENUATION
Each loop has no more than 35 dB of loss at 196 kHz, with driving and terminating impedances of 135 Ω (see
Table 27 below).
H2TU-C-231 List 4E
Table 27. HDSL2 Cable Attenuation Chart
Loss at 196 kHz
Cable Gauge
(dB/kft)
26/0.4 mm 3.88
24/0.51 mm 2.84
22/0.61 mm 2.18
19/0.91 mm 1.54
September 28, 2001
Appendix A - Specifications
Ω
per kft
83
52
32
16
