Front Panel
Message Full Name
LOOPBACK MESSAGES
CLOC Customer Local Loopback
CREM Customer Remote Loopback
NLOC Network Local Loopback
NREM Network Remote Loopback
SMJK Remote SmartJack Loopback
DIAGNOSTIC MESSAGES
A = xx Maximum Loop Attenuation
ACQ Acquisition
ARM HiGain System Armed
BAD RT? No Response from H2TU-R
FERR Framing Bit Error Occurred
FLDL Flash Download
HES HDSL2 CRC Error
LBPV Local Bipolar Violation
M=xx HDSL2 Loop Margin
MNGD Managed
PWR FEED OFF Power Feed Off
PWR FEED ON Power Feed On
SIG Signaling
SYSTEM INFORMATION MESSAGES
CODE xxxx Line Code: AMI, B8ZS
FRM xxxx Frame: SF, ESF, UNFR
LATT xx Loop Attenuation
LIST xx List Number
MARG xx Margin
VER x.xx Software Version Number
(a) System information messages are displayed in Scroll mode. To scroll through the messages, press the MODE pushbutton for
3 or more seconds.
6
Table 2. Front-Panel Display Messages (Continued)
Description
DS1 signal from customer is looped back to the customer at the H2TU-R.
DS1 signal from customer is looped back to the customer at H2TU-C.
DSX-1 signal is looped back to the network at the H2TU-C.
DSX-1 signal is looped back to the network at the H2TU-R.
DSX-1 signal is looped back to the network at the H2TU-R SmartJack
module.
The Attenuation (A) message appears followed by xx, where xx is the
loop attenuation of the longest (maximum loss) span measured in dB.
The multiplexers of the H2TU-C and H2TU-R are trying to establish
synchronization over the HDSL2 loop.
Armed to respond to Intelligent Repeater Loop (ILR) codes.
The H2TU-C does not receive any response from the H2TU-R. Therefore,
the integrity of the H2TU-R or the HDSL2 loop is questionable.
Framing bit error occurred at H2TU-C DSX-1 input.
Flash download of firmware upgrades. Contact Customer Service for
upgrade procedures (see
H2TU-C HDSL2 Loop Cyclical Redundancy Check (CRC) error.
A bipolar violation has been received at the DSX-1 input to the
H2TU-C-231.
Indicates the power of the received HDSL2 signal relative to noise (S/N
with respect to 21.5 dB). Any value of 6 dB or greater is adequate for
reliable system operation.
The H2TU-C-231 is under control of the HMU-319 network management
unit. In this state, the front-panel craft port and pushbuttons are
disabled.
HDSL2 span power has been turned off by setting the PWFD option to
OFF, or HDSL2 span power has been turned off by use of the A2LB
Intelligent Office Repeater (IOR) powerdown code.
Indicates that the HDSL2 loop is not grounded or shorted.
The transceivers of the H2TU-C and H2TU-R are trying to establish
contact with each other over the HDSL2 loop.
(a)
DS1 line code: Alternate Mark Inversion (AMI) or Bipolar with 8-Zero
Substitution (B8ZS).
Defines the type of frame pattern being received from the DSX-1:
SuperFrame (SF), Extended SuperFrame (ESF), or Unframed (UNFR).
Current loop attenuation threshold setting is measured in dB.
List number of the H2TU-C-231.
Current margin threshold setting is measured in dB.
Software version number of the H2TU-C-231.
September 28, 2001
LTPH-TP-1034-01, Issue 1
"Appendix D - Product Support" on page
H2TU-C-231 List 4E
63.)
