Overview
–
Supports the in-band 100 loopdown command for all loopback modes
–
Supports the in-band 100000 loopup command when SmartJack loopback (LPBK) option is enabled
–
Power Back Off Customer (PBOC) and Power Back Off Network (PBON) options for configuring power
output levels
•
Compatible with Small Cross-Section Shelf (SXSS) and equipment
•
Digital Data Service (DDS) latching loopback
•
Network Management and Administration (NMA) interface
•
Supports interoperability
DS1 is used throughout this document to refer to either the remote unit's DS1 interface or the
line unit's DSX-1 interface.
C
OMPATIBILITY
The H2TU-C-231 List 4E is designed to mount in 220 mechanics shelves. For a list of compatible shelves, see
"Appendix C - Compatibility" on page
A
PPLICATIONS
HiGain HDSL2 systems provide a cost-effective, easy-to-deploy method for delivering T1 High Capacity Digital
Service (HCDS) over a single copper pair. HiGain HDSL2 systems support a multitude of network connections.
• The service is deployed over one unconditioned, non-loaded copper pair.
• Conventional, inline DS1 repeaters are no longer required.
•
Cable pair conditioning, pair separation, and bridged tap removal are not required.
Each loop has no more than 35 dB of loss at 196 kHz, with driving and terminating impedances of 135 Ω . In
general, HiGain HDSL2 systems:
• Operate effectively in the same cable binder group with other HDSL2 lines, HDSL, DS1, ADSL, SDSL,
POTS, DDS, and other transmission schemes.
•
Can be used with customers requiring DS1 service on a temporary or permanent basis.
• Provide a means of quickly deploying service in advance of fiber-optic transmission systems.
