Print More Materials, All For Application HIGH-TEMPERATURE SERIES 3D PRINTER MAGIC-HT-MAX Operating Instructions * Please read this manual carefully before starting to operate. This device is a Class A product. Use in a general indoor environment may cause radio interference and therefore requires the user to take appropriate protective measures.
Page 2
Print More Materials, All For Application The contents of this operating instructions may be updated periodically. Scan the QR code or visit the link below to get the latest version. www.iemai3d.com/index.php/download/ - 2 -...
1. Overview 1.1 Printer Overview IEMAI high-performance material 3D printer, the Magic-HT-MAX, is a 3D printing equipment based on the principle of fused filament fabrication (FFF) technology. It has a printing temperature of up to 500℃, a hot bed temperature of 200℃, and a chamber temperature of 150℃, which supports...
Print More Materials, All For Application 1.2 Precautions First of all, thank you for choosing IEMAI 3D Printer! This device is a Professional equipment, please read this manual carefully before starting to use, this manual contains important information about the installation, operation, maintenance, and common problems of the 3D printer, the company is not responsible for all losses caused by violation of the cautions and operating procedures given in this manual。...
Print More Materials, All For Application 1.3 Safety The device has a specialized motion structure, control system and electrical control parts, users need to pay careful attention to the safety label when using it to prevent burns, pinching, electric shock or other safety problems. The maximum temperature of the print head of this equipment can reach 500 °...
Print More Materials, All For Application 2.2 Device Layout Top Cover Emergency Stop 7-Inch Touch Screen Filament Box Front Door Chamber Temperature Controller Date Transfer Area Main Electric Box Vacuum Pump Box Material Box Door Moisture-Proof Storage - 9 -...
Page 10
Print More Materials, All For Application Internal Chamber - 10 -...
Page 11
Print More Materials, All For Application Cooling Fan Filament Box Electric Box Pressure Gauge Air Pump - 11 -...
Page 12
Print More Materials, All For Application Cooling Fan Built-In Light Built-In Camera Motor Power Outlet - 12 -...
Print More Materials, All For Application 2.3 Interactive Interface The interactive interface of the device adopts a 7-inch Chinese-English color touch screen (resistive). Please read the following interface instructions carefully before first use. Logic diagram of interactive interface - 13 -...
Print More Materials, All For Application 2.3.1 System Interface Figure 1: Main interface Figure 2: System interface Figure 3: Info interface Click "Info" to go to Figure 3 This interface allows you to Click "System" to go to Figure 2 view the current coordinates of 2.
Print More Materials, All For Application 2.3.2 Tool Interface Figure 1: Main interface Figure 2: Tool Interface Figure 3:Manual Click "Tool" to go to Figure 2 Click "Manual" to go to Figure 3 Here can do the following Click "Preheat" to go to Figure 4 Select the moving unit of 0.1-10mm Click "Filament”...
Print More Materials, All For Application 2.3.3 Print Interface Figure 1: Main Interface Figure 2: File Interface Figure 3: Print Interface Click "Print" to go to Figure 2 Check Specify G-code file to print or 1. This interface is the main delete the file interface in print You can view thumbnails...
Print More Materials, All For Application 3. Device Usage 3.1 Unpacking Step 1 Step 2 Check if the packaging is complete The equipment is tightly packed and protected If there is a damage, please feedback by taking Please be patient in removing the package photos in time If you need to use tools, such as knives, scissors If serious damage, please refuse to receive...
Print More Materials, All For Application 3.2 Check Equipment Motion Step 1 Step 2 Step 3 Plug in the power connector at the It is shown in Figure 3 Use 6mm² cable to connect rear of the machine to the main AC220V single-phase power socket power supply Step 4...
Print More Materials, All For Application 4.1.1 Use Auto Leveling To Print Step 1 Step 2 Step 3 When starting the machine, After passing the self-test, click The X-axis (transverse) Y-axis observe whether the automatic return to zero (vertical) is zeroed in turn, , and leveling self-test passes.
Page 21
Print More Materials, All For Application Step 4 Step 5 Step 6 1. Wait for return to zero 2. Click level to use auto leveling. 3. Wait for the machine to automatically find 49 points to build, then printing platform will start printing The mode setting is as follows: 1.
Page 22
Print More Materials, All For Application For the first use, when the platform rises to touch the nozzle, if you hear a "bang" sound and the machine is powered off, which indicates that the emergency stop limit is triggered. Need to unplug the limit connector and open the right electric box cover, find the leakage protector and press the gray button, switch up to start...
Print More Materials, All For Application 4.1.2 Use Mechanical and electronic limit to Print Step 1 Step 2 Step 3 1. Using the working range of The use of traditional mechanical The height of the platform is adjusted 0.1mm and 10mm, so that the leveling point by point in a clockwise way.
Print More Materials, All For Application Load/Unload Filament Step 1 Step 2 Step 3 Straighten the material Cut the material to the tip Print temperature according to the material to be loaded Preheat Refer to Step 10 for the preheating temperature of different materials Step 4 Step 5...
Page 25
Print More Materials, All For Application Step 5 Step 8 Step 9 When unloading materials, press the After the material is out of the 1. Click “ ” to unload materials distal extrusion clamp after the gear, pull it out manually, and fix 2.
Step 3 Insert the USB into the USB port Click “ ” ready to start In the IEMAI slicing software, the and select the slice file printing code will be saved to the SD card, please see the software tutorial for...
Print More Materials, All For Application 4.4 Disassembly Model Step 1 Step 2 Step 3 the finished model on the Turn off the vacuum adsorption After taking down the platform, printing platform switch carefully shovel the model from all sides slowly 4.5 PEEK Material Printing Precautions Materials/Parameters Printing Temp...
Print More Materials, All For Application 4.6 PC-Based WIFI LAN control Step 1 Step 2 Step 3 ChiTu HB V1.10(1).zip Copy the generated file to the Installation of CHITU HB/PRO Enter the software interface SD card software Enter the name and password of and put it on the machine to the WIFI in the lower right corner print once...
Print More Materials, All For Application 5. Function Introduction 5.1 Power Failure Recovery Step 1 Step 2 Step 3 If the machine suddenly powers off 1. Turn the power back on On this screen, select Yes to during the printing process 2.
Print More Materials, All For Application 5.3 Chamber Temperature Setting Step 1 Step 2 Step 3 Schematic diagram of the chamber Long press the temperature 1. Through transposition keys, temperature controller setting key to enter the setting increase/decrease keys interface 2.
Print More Materials, All For Application 5.4 Moisture Proof Cabinet Setting Step 1 Step 2 Step 3 Click Settings Use the increase/decrease keys Enter the settings screen Set the specified target humidity Target humidity value jump Recommended setting is a Pedestal humidity controller minimum of 10% RH diagram...
Print More Materials, All For Application Maintenance and Care This equipment belongs to high temperature equipment, the internal use environment temperature is high, do not replace the conventional parts to avoid machine failure. Please deal with the problem under the guidance of professionals. 6.1 Maintenance of Linear Guide and Ball Screw Ball screw and linear guide are the guarantee to keep secure operation, and the correct maintenance can effectively increase the service life of the machine.
Print More Materials, All For Application Dust Removal from Electrical Box Fans Step one. Check the dust condition of the dust cover and fan blades of the electrical box fan. Timely cleaning the dust of the cooling fan helps to improve the working environment of the motherboard and prevent the drive from overheating and out-of-step phenomenon.
Print More Materials, All For Application Nozzle Maintenance (1) Cleaning: In the printing process, there will be excess filament residue melted on the nozzle, which will affect the printed items, so it needs to be cleaned. Step 1: Heat up the nozzle (subject to the last printing temperature) Step 2: Use tweezers to hold soft fiber cloth or some other high temperature resistant soft items to wipe clean...
Print More Materials, All For Application Height Adjustment for Dual Nozzle Step 1 Step 2 At a fixed position Open the cover Use an opaque sheet to shade the inner sensor 1.Move the Z-axis so that the print head is at the height of an auxiliary block with the platform Print head switch to print head # 2 2.
Print More Materials, All For Application Dual Nozzle Spacing Adjustment Method Step 1 Step 2 Step 3 Print a two-color miniature 1. Get printed as shown in the Open the slicing software figure Adding the paint tower Adjust the parameters in the 2.Take the left printhead as standard print head settings White left nozzle...
Print More Materials, All For Application Print Head Disassembly The equipment is double quick detachable print head, the left head is equipped with a high temperature and a low temperature dual print head, the right head is also a low temperature and a high temperature two printing heads.
Print More Materials, All For Application 7. Common Problems and Their Solutions A few common problems are listed, for more questions please contact the technician directly. 7.1 Movement Problem Solution Problem 1: When extruding, the extrusion gear shake. Increase the print head temperature or determine if the head is clogged or needs to be reloaded with material.
Print More Materials, All For Application 7.3 Print Problem Solution Problem 1: Prompt #1 or #2 no material, cannot print Add material at the filament-warning test properly Problem 2: The print appears to be detached from the After determining that the platform is able to print bottom and is carried away that material, adjust the platform and nozzle gap when the zero point is small (see Printing - Installing...
Print More Materials, All For Application Clean Up Carbon Blockage Problem Solution Treatment method 1: Heat the nozzle until the material inside melts, insert a needle with the same aperture size as the nozzle (a 0.4mm needle is provided) into the nozzle, click and extrude downward, and slowly pull out the needle.
Page 41
Print More Materials, All For Application Appendix A: The difference between high and low temperature of the print head High Temperature Normal Temperature Note: High temperature nozzle is suitable for printing materials with temperature over 300 ℃ Normal temperature nozzle is suitable for printing materials with temperatures below 300 ℃ and is not interchangeable - 41 -...
Page 42
Print More Materials, All For Application Appendix B: How To Use Platform Glue Stick 1. Apply solid glue uniformly to the printing platform for the first time before printing. As shown in the figure, apply the corresponding area vertically or vertically according to the size of the printing model. Note: The temperature of the carbon fiber plate should not exceed 50℃, otherwise the high temperature will melt the glue stick quickly and lead to uneven thickness of the glue.
