Ultrasonic level sensor
Table of Contents

Advertisement

Quick Links

BA237O/98/en/01.10
52027986
185564 01/10 01
Valid as of software version
V 01.04.00 (amplifier)
V 01.04.00 (communication)
Ultrasonic Level Sensor
LUC-M** with HART/4 mA ... 20 mA
Operating instructions
LUC-M10
HART
HART
R R
FIELD COMMUNICATION PROTOCOL
C
LUC-M40
LUC-M30
LUC-M20
