Assa Abloy Sargent 10X Line Installation Instructions

Installation Instructions
Installation Instructions
10X Line with BHW Trim
Tools Required
1
• 5/32" drill bit
• #2 Phillips screwdriver
Product Components
2
9
14
Door Preparation
3
1. Use template A8335 to mark the door (Figure 1).
2. Drill the door according to the template.
3. Verify the dimensions (Figure 2).
4. Install the strike (Figure 3)
Backset must
match latch
Desired
height
above
DOOR
floor
IMPORTANT
• The accuracy of door preparation is critical for proper functioning and security of this lever handle lock. Misalignment can
cause premature wear and a lessening of security.
• Be sure to verify backset before marking and drilling door.
For installation assistance contact SARGENT
1-800-543-3658 • techsupport.sargent@assaabloy.com • www.sargentlock.com
Copyright © 2022, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved.
Reproduction in whole or in part without the express written permission of ASSA ABLOY Access
and Egress Hardware Group, Inc. is prohibited.
• 1/2" drill bit
®
• T25 Security Torx screwdriver
2
8
7
6
13
10
11
12
2x 7/16" (11mm) hole
Template
1" (25mm)
hole
2-1/4"
(57mm)
Door bevel
FRAME
1-1/8"
(29mm)
• 7/16" drill bit
• T15 Security Torx
5
4
3
3x 1/2" (13mm) hole
1-11/16"
(43mm)
2-3/4"
(70mm)
4-3/4"
2-1/8"
(120mm)
(54mm)
hole
5/32" (4mm)
5/8"
(16mm)
®
screwdriver
Fig.
1 Inside escutcheon & lever assembly
Outside escutcheon & lever
2
assembly
3 Inside spring housing assembly
Screws - through-bolt (2) #10-32
4
x 1-1/4"
Lockbody assembly with mounting
5
plate
6 Outside spring housing assembly
7 Cylinder spacer
8 Cylinder
15
9 Key
10 Latch
11 Screws - latch (2) #8-32 x 3/4"
12 Screws - strike (2) #12-24 x 3/4"
1
13 Strike
14 Strike box (Optional)
Screws- through-bolt (3) #10-24 x
15
3-1/2"
A8334 07/22
• 1/8" drill bit
Description
Strike Box
Attaching Screws
#12 -24 x 3/4"
