Assa Abloy Sargent 10G13 Installation Instructions

Tools
#2 Phillips screwdriver
Push pin (provided)
7/16" drill bit
1/8" drill bit
2-1/8" bore
1" bore
2
1
Parts
1. Inside lever
2. Scalp (2)
3. Screws – mounting plate
(2) #6 x 3/4" self-tapping
4. Spacer bushing (2)
* Used with 68 Function only

Door Preparation

• All doors should be properly reinforced for lock support. If support is not provided, contact door manufacturer.
• For all metal door preparations use template A4375, EXCEPT for functions 10G70 or 10G71 which uses template 4409
(provided), or functions 10U93, 10U94 and 10U94-2 which require template A4375.
• For all wood door preparations use template A6719, EXCEPT for functions 10G70 & 10G71 which uses template 4409
(provided), or functions 10U93, 10U94 and 10U94-2 which requires template A4375.
• Template information is available on our website, www@sargentlock.com.
• Mark and Drill Holes
IMPORTANT:
Fold template onto high
edge of door bevel
Backset
must match lock
(2-3/8" or 2-3/4")
38" from
Finished Floor
DOOR
5
6
4
3
Inside of Door
5. Inside rose assembly
6. Screws – through-bolt
(2) #10-32 x 1-1/4"
7. Lockbody
8. Outside rose assembly
9. Cylinder spacer
1"
(25mm)
hole
Template
2-1/4"
(57mm)
Door
Bevel
FRAME
INSTALLATION INSTRUCTIONS FOR
10 Line Lever Lock
For installation assistance, contact SARGENT at 800-727-5477
www.sargentlock.com
8
7
Outside of Door
1 4
15
16
1 7
• Final Door Prep
7/16" (11mm) hole
5/32"
(4mm)
1-1/8"
(29mm)
IMPORTANT: Deadlocking latch must
stop on strike when door is closed
(Patents Pending)
2
9
4
1 0
(secured side)
10. Cylinder
11. Outside lever
12. Key
13. Push pin
14. Latch
15. Screws – latch & strike
(4) #8-32 x 3/4"
16. Strike
17. Strike box
• Frame Prep for Strike
Centerline of
latch front and
strike
2-1/8"
Screws (2)
(54mm)
#8-32 x 3/4"
hole
© SARGENT Manufacturing Company
1 2
1 1
1 3
Strike
1
A7133J
