RG-SS6510 4C Series Switch Hardware Installation and Reference Guide
The M6500-08CQ provides 8 QSFP28 ports and supports hot swapping of QSFP+ modules. Both fiber modules and
DAC can be used.
Indicator
Indicator
System indicator
QSFP+ port indicator
Specifications
Module M6500-08CQ
Device RG-S6510-4C
Port Type 8 100G QSFP28 ports
See Appendix B
Transmission
Medium
Hot Swapping Not Supported
Power Consumption <57W
EMC GB9254-2008 CLASS A
Safety specification GB4943-2011
Operating
0° C to 45° C (32° F to 113° F)
Temperature
Storage
-40° C to 70° C (-40° F to 158° F)
Temperature
Operating Humidity 10% to 90% RH (non-condensing)
Weight 0.5 kg (1.10 lbs)
Dimensions
200 mm x 207 mm x 41 mm (7.87 in. x 8.15 in. x 1.61 in.)
(W x D x H)
QSFP28 ports support both 100G and 4x25G modes.
100G ports support DAC. QSFP28 ports support 3m cables. See Appendix B for details.
Panel
Status
Identification
Off
Solid red
Status Blinking green
Solid green
Solid yellow
Off
1F-8F
Solid green
(4*25G/4*10G)
Blinking green
Off
1F-8F Solid green
(1*100G/1*40G)
Blinking green
The supported module may change. Please contact Ruijie Networks for details.
Meaning
The system is not powered up.
The module fails or resets.
The system is initializing.
The system is operational.
The temperature exceeds the threshold.
The port is down.
The port is connected at 25G/10G.
The port is receiving or transmitting data at 25G/10G.
The port is down.
The port is connected at 100G/40G.
The port is receiving or transmitting data at
100G/40G.
Product Overview
