RG-SS6510 4C Series Switch Hardware Installation and Reference Guide
Specifications
Module M6500-24VS2CQ
Device RG-S6510-4C
Port Type 24 25G SFP28 ports and 2 100G QSFP28 ports
See Appendix B
Transmission
Medium
Hot Swapping Not Supported
Power Consumption <57W
EMC GB9254-2008 CLASS A
Safety specification GB4943-2011
Operating
0° C to 45° C (32° F to 113° F)
Temperature
Storage
-40° C to 70° C (-40° F to 158° F)
Temperature
Operating Humidity 10% to 90% RH (non-condensing)
Weight 0.6 kg (1.32 lbs)
Dimensions
200 mm x 207 mm x 41 mm (7.87 in. x 8.15 in. x 1.61 in.)
(W x D x H)
M6500-24VS2CQ supports 25G SFP28 and 10G SFP+ modules.
25G/10G ports support DAC. SFP+ ports support 1m, 3m and 5m cables. See Appendix B for details.
1.2.2 M6500-08CQ
Module Appearance
Figure 1-7 M6500-08CQ
Notes: 1. Status Indicator
2. 1F-8F Port Status Indicator
External Ports
Blinking green
The supported module may change. Please contact Ruijie Networks for details.
The port is receiving or transmitting data at
100G/40G.
3. 100G/40G QSFP28 Port
Product Overview
