Center; Reset - Interphase Proble Operation Manual

Track Plotter Symbols
+ Starting Position
W
Waypoint selected in
navigation receiver
+ Center of plot screen

Center

By pressing the "CENTER" soft key, your current
position will be moved to the center of the track plot
display and the track line dots will be shifted accordingly.

Reset

The "RESET" soft key in the menu restarts your track
plotting by placing your present position in the center of
the track plot screen and erasing all track line dots.
Note: The Probe has both a full screen and a split screen
track plotter. Both of these Views are updated
automatically, regardless of what display screen is in use.
Although these two track plot views are similar, the user
may select different ranges for each of these views. For
example, the full screen track plotter can be set up for a
64 mile range, while the split screen track plotter can be
set up for 1/4 mile! This allows you to get two different
instantaneous views of your boat's movement by
selecting the two different track plot views. For example,
you could select the range of 64 miles for the full screen
to show far off course changes, but select a range of only
1/4 mile on the split screen track plotter to show more
detail of your boat's movement.
30
