R.V.R. Elettronica TEX150-LCD/S User Manual

Hide thumbs Also See for TEX150-LCD/S:
Table of Contents

Advertisement

Quick Links

TEX150-LCD/S
User Manual
Volume 1
manufactured by
Italy

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TEX150-LCD/S and is the answer not in the manual?

Questions and answers

Related Manuals for R.V.R. Elettronica TEX150-LCD/S

Summary of Contents for R.V.R. Elettronica TEX150-LCD/S

  • Page 1 TEX150-LCD/S User Manual Volume 1 manufactured by Italy...
  • Page 2 Limitations of use can apply in respect of operating freuency, transmitter power and/or channel spacing. Declaration of Conformity Hereby, R.V.R. Elettronica SpA, declares that this FM transmitter is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.

  • Page 3: Table Of Contents

    TEX150-LCD/S Table of Contents 1. Preliminary Instructions 2. Warranty 3. First Aid 3.1 Treatment of electrical shocks 3.2 Treatment of electrical Burns 4. Removing the Packing 4.1 Package 4.2 General description 5. Quick Installation and Use Guide 5.1 Preparation 5.2 Use 5.3 Settings and calibration...
  • Page 4 TEX150-LCD/S This page was intentionally left blank Rev.1.0 - 29/11/04 User Manual...

  • Page 5: Preliminary Instructions

    In a residential place this equipment can cause hash. In this case can be requested to user to take the necessary measures. R.V.R. Elettronica SpA reserves the right to modify the design and/or the technical specifications of the product and this manual without notice.

  • Page 6: First Aid

    TEX150-LCD/S If your dealer cannot help you, contact R.V.R. Elettronica and explain the problem. If it is decided to return the unit to the factory, R.V.R. Elettronica will mail you a regular authorization with all the necessary instructions to send back the goods.

  • Page 7: Treatment Of Electrical Burns

    TEX150-LCD/S Figure 3 Figure 4 Figure 5 • In case of only one rescuer, 15 compressions alternated to two breaths. • If there are two rescuers, the rythm shall be of one brath each 5 compressions. • Do not interrupt the rythm of compressions when the second person is giving breath.

  • Page 8: Removing The Packing

    PLL (Phase Locked Loop) system. The TEX150-LCD/ S achieves frequency lock in a maximum time of thirty seconds from switch-on. The TEX150-LCD/S is able to work on the entire frequency band without the need for calibration or setting.
  • Page 9 TEX150-LCD/S The microprocessor control system includes an LCD on the front panel and a user keyboard, and implements the following functions: • Output power setting Working frequency setting • • Power delivery enabling and disabling Exciter work parameter measurement and display •...

  • Page 10: Quick Installation And Use Guide

    Use the following type of fuse: 6.3 A 5x20 Make sure the TEX150-LCD/S switches are in the “OFF” position. The exciter features two switches: one built into the VDE base for the mains power supply cable, which cuts off mains power completely, and the second is located on the front panel and bypasses the machine’s switching power supply.

  • Page 11: Use

    From the “Fnc” menu, enable power delivery. 5.3 Settings and calibration The only manual adjustments required for the TEX150-LCD/S are those related to the levels and the audio operation mode. The back panel of the device features a trimmer for each exciter input; the labels indicate which trimmer refers to each input.

  • Page 12: Software

    TEX150-LCD/S To adjust the input sensitivity level, remember that the preset menu contains the instantaneous modulation level and that an indicator reads a level of 75 kHz. For a correct adjustment, we therefore recommend you apply to the machine input a level equal to the maximum level of your audio program and adjust the related trimmer until the instantaneous deviation coincides with 75 kHz.
  • Page 13 TEX150-LCD/S The bar to the right of “Mod” indicates the modulation progress in real time; the broken bar indicates the maximum nominal modulation of 75 kHz (100%). To vary the set power level, select the line pertaining to power with the DOWN key and keep the ENTER key pressed until you have entered “modify”...
  • Page 14 TEX150-LCD/S Accensione Menu di Selezione ENTER Menu Funzione ENTER Menu Potenza ENTER Menu P.A. ENTER Menu Impostazioni ENTER Menu Varie ENTER Menu Versione ENTER Menu Canali Figure 5.1 5.4.1 Function menu (Fnc) From this menu you can set the deviation display mode, enable or disable power delivery by the exciter and set the power percentage of Power Good.
  • Page 15 TEX150-LCD/S power goes below the Power Good threshold value, the machine changes the status of a pin contained in the DB15 “Remote” connector located on the back panel (fig. 6.2 note [14] ). The Power Good percentage value refers to the machine nominal power, i.e. 150W, and not to the direct delivered power.
  • Page 16 TEX150-LCD/S By pressing and keeping pressed ENTER, you can change the set frequency with the UP (frequency increases) and DOWN keys. After having set the new frequency value, press ENTER to confirm your choice; the exciter will unlock from the current frequency (the “LOCK” LED goes off) and will lock on a new working frequency (“LOCK”...
  • Page 17 TEX150-LCD/S 5.4.7 Channels menu (L&R) The right and left channel input levels are depicted with horizontal bars, as shown in the following figure. The hatched pointer indicates the level that corresponds with the total deviation at 100%, and is useful to regulate the input levels of the audio channels.

  • Page 18: External Description

    TEX150-LCD/S 6 External Description This chapter describes the elements found on the front and back panels of the TEX150-LCD/S. 6.1 Front Panel Figure 6.1 [1] AIR FLOW Air flow passage grid [2] ON Green LED, lit when the exciter is powered...

  • Page 19: Back Panel

    TEX150-LCD/S 6.2 Back Panel Figure 6.2 [1] PLUG Standard IEC socket for mains power supply, 90-260V 50-60Hz. [2] AIR FLOW Air flow passage grid. [3] R.F. OUT RF output connector, N-type. [4] 24VDC IN + 24V external power supply connector. Positive pole.
  • Page 20 TEX150-LCD/S [31] SCA2 ADJ Trimmer for adjusting the SCA2 input levels. [32] LEFT-MONO ADJ Trimmer for adjusting LEFT-MONO input levels. [33] LEFT-MONO XLR connector for LEFT-MONO channel audio input. 16 / 24 Rev. 1.0 - 09/07/04 User Manual...

  • Page 21: Connectors Description

    TEX150-LCD/S 6.3 Connectors description 6.3.1 RS232 Type: DB9 Male TX_D RX_D Connected internally with 6 Connected internally with 4 Connected internally with 8 Connected internally with 7 6.3.2 Service (for factory parameter programming) Type: DB9 female TX_D RX_D Connected internally with 6...
  • Page 22 TEX150-LCD/S 6.3.4 Remote Type: DB15 female Pin Name Type Meaning Interlock Bypasses power if closed at GND Ext AGC FWD IN Ext. signal for power limitation (AGC) Ground SDA IIC IIC communication serial data VPA Tlm OUT anal. PA power supply voltage: 5 V for 62 V FWD tlm OUT anal.

  • Page 23: Technical Specifications

    TEX150-LCD/S 7. Technical Specifications 7.1 Mechanical characteristics Panel size 483 mm (19") x 132.5 mm (2 HE) Chassis depth 389 mm (15.32") Total depth 400 mm (15.75") Weight Aprox. 6.5 Kg Operating temperature -10 °C 50 °C 7.2 Electrical characteristics...
  • Page 24 TEX150-LCD/S SCA/RDS inputs Unbalanced BNC SCA/RDS input impedance 10 kOhm SCA/RDS input level -8dBu +13dBu, continuous fine adjustment with trimmer Outputs RF Out N-type female connector with 50 Ohm impedance RF Monitor BNC connector, approx. level -60dB compared to RF output, 50 Ohm impedance...
  • Page 25 TEX150-LCD/S Stereo operation S/N FM > 75dB (typical 78dB) compared to ±75kHz peak, measured in the 20Hz −23kHz band with 50 us deemphasis, demodulated L&R, RMS detector > 65dB compared to ±75kHz peak, CCIR not weighed with 50 us deemphasis, demodulated L&R, Qpk detector...

  • Page 26: Basic Functions

    TEX150-LCD/S 8. Basic Functions A schematic view of the modules and connections that make up the TEX150-LCD/S is shown in fig. 8.1. Controller Power R.F. Output Main Card Card Amplifier Stereo Coder Telemetry Mains Power Supply Figure 8.1 Following is a brief description of the functions of each module. The complete diagrams and module layouts are contained in the "Technical Appendix"...

  • Page 27: Power Amplifier

    TEX150-LCD/S • Modulation • RF amplification (Driver) The board also features a stereophonic coder. 8.3.1 Audio input section The audio input section contains the circuits that perform the following functions: Input impedance selection • 15 kHz filtering of the mono channel •...

  • Page 28: Telemetry Board

    TEX150-LCD/S Measures direct and reflected power by means of directional couplers • • Measures the current absorbed by the power amplifier • Measures temperature • Filters the pass low of the output RF signal This board also features an RF sampling of approximately -30dB RF with respect to the output, which is available on a BNC connector below the transmitter output connector.
