  • Page 1 TLC300 User Manual Manufactured by Italy...
  • Page 2 07/04/2003 Revision History Version Date Reason Editor 07/04//2003 New version J. Berti TLC300 - User Manual Version 1.0 © Copyright 2003 R.V.R. Elettronica SpA Via del Fonditore 2/2c - 40138 - Bologna (Italia) Telefono: +39 051 6010506 Fax: +39 051 6011104 Email: info@rvr.it...

  • Page 3: Table Of Contents

    6.1 Local enquiries 6.2 Remote enquiries with remote control software 6.3 Remote enquiries with GSM modem + SMS 7. External Features 7.1 TLC300 description 7.2 Change over card 7.3 Additional Standard Telemetry Card 7.4 Description of service connectors PIN 8. Identification and Access to modules 8.1 CPU card...
  • Page 4 TLC300 This page was intentionally left blank Rev. 1.0 - 07/04/03 User Manual...

  • Page 5: Preliminary Instructions

    This is a "CLASS A" equipment. In a residential place this equipment can cause hash. In this case can be requested to user to take the necessary measures. R.V.R. Elettronica SpA reserves the right to modify the design and/or the technical specifications of the product and this manual without notice.
  • Page 6 TLC300 This page was intentionally left blank 2 / 42 Rev. 1.0 - 07/04/03 User Manual...

  • Page 7: Warranty

    2 If your dealer cannot help you, contact R.V.R. Elettronica and explain the problem. If it is decided to return the unit to the factory, R.V.R. Elettronica will mail you a regular authorization with all the necessary instructions to send back the goods.
  • Page 8 Replacement and warranty parts may be ordered from the following address. Be sure to include the equipment model and serial number as well as part description and part number. R.V.R. Elettronica SpA Via del Fonditore, 2/2c 40138 BOLOGNA ITALY Tel.

  • Page 9: First Aid

    TLC300 3. First Aid The personnel employed in the installation, use and maintenance of the device, shall be familiar with theory and practice of first aid.. 3.1 Treatment of electrical shocks 3.1.1 If the victim is not responsive Follow the A-B-C's of basic life support •...

  • Page 10: Treatment Of Electrical Burns

    TLC300 3.1.2 If victim is responsive • Keep them warm Keep them as quiet as possible • Loosen their clothing (a reclining position is recommended) • Call for medical help as soon as possible • 3.2 Treatment of electrical Burns 3.2.1 Extensive burned and broken skin...

  • Page 11: General Information

    The devices of which the SCM-TLC system consists are all made in 19" 2U rack containers, with the exception of the TLC300, which is 19" 1U size. Entirely assembled with modules fitted on the base of the device and connected with snap-in fitting connectors, they are easily removed, substituted and added.

  • Page 12: Configuration

    4.1.2 Telemetry Two devices are available for station telemetry, depending on complexity and the number of parameters to be acquired: TLC300: includes 2 telemetry cards, for a total of 16 balanced analog inputs, 32 • digital/analog inputs and 16 relay outputs.
  • Page 13 TLC300 Device Type Version bal. IN dig./an. IN OUT rly SCM1-LCD SCM 1+1 & TLM SCM1-LCD SCM 1+1 & TLM SCM1-LCD SCM 1+1 & TLM SCM1-LCD SCM 1+1 & TLM SCM4/1-LCD SCM N+1 & TLM SCM4/1-LCD SCM N+1 & TLM SCM4/1-LCD SCM N+1 &...
  • Page 14 TLC300 TLC2000 \T0 TLC2000 \T1 TLC2000 \T2 TLC2000 \T3 TLC2000 \T4 TLC2000 \T5 TLC2000 \T6 TLC300 \T0 TLC300 \T1 TLC300 \T2 10 / 42 Rev. 1.0 - 07/04/03 User Manual...

  • Page 15: Quick Reference

    TLC300 5. Quick reference The purpose of this chapter is to summarize the points that should be adhered to for using the machines. Should any point not be fully comprehensible, such as how to operate the machine the first time, the description of the operating system should be read very carefully.
  • Page 16 TLC300 Description 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 None PSTN PAGER 1200 2400 9600 19200 Address X X X X X X Iic board n°...
  • Page 17 TLC300 5.1.2.3 Audio signal missing (PTX-LCD only) The audio signal presence control is carried out only if the exciter of the transmitters is a PTX-LCD series exciter comes, therefore, generated an alarm message that comes memorizzato locally and comes subsequently sended through modem to the numbers and in the modalities indicated from the carried out programming.
  • Page 18 TLC300 5.1.3.3 Remote signalling with modem GSM • The TLC calls in sequence all the telephone numbers memorized in the memory and communicates the code and alarm description (from the other part must be connected a PC with the TELECON software of telecontrollo in stand-by or a program of attended communication in of messages from the modem).

  • Page 19: System Status Enquiries

    TLC300 6. System Status Enquiries 6.1 Local enquiries The SCM and TLC2000 devices indicate their status locally and concisely by means of the indicator lights on the front panel. More detailed information can be obtained from the setting and configuration menus.
  • Page 20 TLC300 This page was intentionally left blank 16 / 42 Rev. 1.0 - 07/04/03 User Manual...

  • Page 21: External Features

    TLC300 7. External Features This chapter describes the components located on the front and rear panels of the SCM-TLC systems. 7.1 TLC300 description 7.1.1 Front panel [1] ON It indicates the operation of the equipment [2] DIP-SWITCH It allows the express setting of the present dip-switches User Manual Rev.
  • Page 22 Trimmer for adjusting voltage at input of the machine's internal circuitry voltage NOTE: In figure is represented the rear panel of a TLC300 in T2 version. NOTE: The DB25 connectors (7÷9) and the trimmers (10) belong to standard telemetry card n.1, wich is always present, whatever the TLC300 configuration. This card manages the commands, the telemetry operations and standard alarms.

  • Page 23: Change Over Card

    TLC300 7.2 Change over card These are normal telemetry cards but are used by the managing firmware for controlling the parameters of the change over card which affect machine operations. Acquires telemetry data in two ways: • Balanced analog with a limit voltage which can be adjusted between 2V and 12V using a trimmer (eight inputs);...
  • Page 24 TLC300 7.2.1 Balanced Analog Input Each of these connectors can be used to connect eight balanced analog signals to the device, as indicated in the table; each input accepts a voltage between 2 and 12V. The table summarizes the functions to which a few balanced analog inputs of this card are dedicated.
  • Page 25 TLC300 The maximum current which can be passed through the contacts is 500mA at 24V. The contacts of the relay switches of this connector are used to command the switching on and off of TXs. The commands to switch on or off for the EXCiters , and for the Power Amplifiers are given in different way.
  • Page 26 TLC300 7.2.4 Description of connectors reserved PINs This section deals with the connectors used by the device for the change over operations. 7.2.4.1 Balanced analog input 1 (Connector [6]) Type: DB25 female Forward power level (+) Reflected power level (+)

  • Page 27: Additional Standard Telemetry Card

    TLC300 7.3 Additional Standard Telemetry Card This is a normal telemetry card, but the system management software uses it to control other parameters. The card internal address must always be the last one of the chain. 7.3.1 Balanced Analog Input The balanced analog inputs of this special card are all available by connecting the signals as indicated in the specific chapter.
  • Page 28 TLC300 7.3.5 Description of general alarms connector PIN This section deals with the connector used by the device for the triggering of the general RVR alarms (settable via the "TELECON" program). This connector refers to the last telemetry card inside the machine.

  • Page 29: Description Of Service Connectors Pin

    TLC300 7.4 Description of service connectors PIN 7.4.1 RS232 Interface The DB9 connector in question is the SCM and TLC communications port through which the system is controlled remotely. The meaning of the signals present at the pins is immediate. Notice that the CTS is not managed, in the sense that it is always active.
  • Page 30 TLC300 This page was intentionally left blank 26 / 42 Rev. 1.0 - 07/04/03 User Manual...

  • Page 31: Identification And Access To Modules

    Includes a liquid crystal graphics display, the encoder and several LEDs. This card is not present in model TLC300. User Manual Rev. 1.0 - 07/04/03 27 / 42...

  • Page 32: Telemetry Card

    TLC300 8.3 Telemetry card Acquires telemetry data in two ways: • balanced analog with a limit voltage which can be adjusted between 2V and 12V using a trimmer (eight inputs); • unbalanced analog with a limit voltage fixed at 5V, or digital with 2.2 KOhm internal pull-up which can be switched on using a jumper (sixteen inputs).

  • Page 33: Relay Control Card

    • by switching the audio signal through five BNC connectors, connected as 4- position switches and one common connector. This type of card is not present in the devices for telemetry only (TLC300 and TLC2000). 8.5 Power supply Alternating current with mains voltage 100-120-220-240V which can be selected externally, or 24V direct current.
  • Page 34 TLC300 This page was intentionally left blank 30 / 42 Rev. 1.0 - 07/04/03 User Manual...

  • Page 35: Card Settings

    TLC300 9. Card settings 9.1 Setting of the card internal address A unique address must be assigned to each card, whether relay control or telemetry, which characterizes it and makes it unique for the CPU. Therefore insert a jumper on each of the JP2 and JP3 connectors in the position indicated in the table below.

  • Page 36: Setting Of The Dip-Switches

    TLC300 D35 D36 9.2 Setting of the Dip-Switches The figure shows a part of the panel card that highlights the 24 Dip-Switches, divided into 3 parts of 8 switches each, numbered from one to three. Use the following numbering to determine the position of the individual switch: •...
  • Page 37 TLC300 Modem type Sw 1.1 Sw 2.1 None PSTN PAGER 9.2.1.2 Baud Rate With these two Dip-Switch can be chosen the type of baud rate of the modem as the indications of the table. Sw 3.1 Baud Rate Sw 4.1...
  • Page 38 TLC300 9.2.1.5 Device Type The device have work in three ways:: Generic: The alarms of forward ande reflected power are disabled. Pj : The alarms of forward and reflected power are enabled and the machine connected to to solid state system.
  • Page 39 TLC300 9.2.1.8 Visualization of the alarms through relay In the case of TLC300, since no visualization is present on the frontal panel, a specific relay can be enable in order to supply one simple visualization through the dip-switch 24.3. User Manual Rev.
  • Page 40 TLC300 This page was intentionally left blank 36 / 42 Rev. 1.0 - 07/04/03 User Manual...

  • Page 41: Test Board Description

    TLC300 10. Test Board Description 10.1 The board 10.2 The meant of the clips 10.2.1 Balanced Analog Input Inside the white rectangle are evidences the clips relative to the 8 balanced analogic inputs described in the following table. User Manual Rev.

  • Page 42: Digital/Analog Input

    TLC300 Pin number Meant Balanced analogic input n°1 IN1+, IN1− Balanced analogic input n°2 IN2+, IN2− Balanced analogic input n°3 IN3+, IN3− Balanced analogic input n°4 IN4+, IN4− Balanced analogic input n°5 IN5+, IN5− Balanced analogic input n°6 IN6+, IN6−...

  • Page 43: Rly Output

    TLC300 The tension applicable to these inputs can have values comprised between 0 and The TLC converts these tensions in digital points and that the last use is reserved to the Telecon Program in which the date base will have to be modified inherent the wished input for the destined use.

  • Page 44: Connection To Tlc

    TLC300 10.5 Connection to TLC Relay Out Digital/Analog input Trimmer di regolazione fondo scala Balanced Analog Input 10.6 How to make the tests In order to carry out some simple tests with the card proceed as it follows: 10.6.1 Connection to TELECON...
  • Page 45 TLC300 10.6.2 Balanced Analog Input • Place in ON position the Dip-switches 5 and 6 of SW2. • Verify that moving RV1 it modifies the reading of the analogic instrument called “Balanced Analog input # 1” regarding the first analogic input of the telemetry to which is connected the card.
  • Page 46 TLC300 • Repeat the operation with the Dip-switch 2, than with the Dip-switch 3, verifying that are modified respectively the input Type 8=analogic 10 and Type 8=analogic 11 of the telemetry board and the led “Digital Input #2” and “Digital Input #3”.
  • Page 47 SCM-TLC Appendix A Descrizione del software Telecon / Telecon software description Questa parte del manuale contiene informazioni e dettagli tecnici riguardanti l’uso del software di telecontrollo per i sistemi SCM-TLC. This part of the manual contains informations and technical details about the use of remote control software for SCM-TLC systems.
  • Page 48 SCM-TLC Table of Content 1. Remote Control Software Description 1.1 Functioning 1.2 Installation 1.3 Esecution 1.4 Functioning 1.5 Programation of a remote station 1.6 Structure of the stations. 1.7 Structure of the database 1.8 Creation of groups and stations 1.9 Creation and editing of the Personalization window 2.

  • Page 49: Remote Control Software Description

    The connection is always realized starting from the first module, either when the station is composed of several modules (TLC300, TLC2000, SCM) or when the station is composed of a single module (PTXLCD).

  • Page 50: Esecution

    SCM-TLC 1.3 Esecution Double click on the "Telecon 32bit" icon present on the desktop or select Telecon 32bit from the "Start" menu -> Programs -> TLC32bit -> “, in order to start the program. 1.3.1 How to choose and configurate a station In the main window it is possible to choose the station you wish to call and edit the parameters that refer to comunication.
  • Page 51 SCM-TLC "Station Configuration" containing the composition of the station. • When you click on the "Edit connections" button (6) the window shown in fig 3 is • displayed, from there you can edit the different connection parameters of each station. Forward /Back button to select the stations...

  • Page 52: Functioning

    SCM-TLC building. Please kindly contact R.V.R. S.p.A. if you wish to put additional stations. 1.3.2 Connection When the station is selected, press "START" (3). The connection window is displayed, and it will remain displayed until the connection is completed. In case the telephone line is busy, it will be possible to make a new connection attempt by pressing the "Retry"...
  • Page 53 SCM-TLC In order to change some levels such as attenuation of the inputs and the output power percentage of the PTXLCD, double click on the measurement that you wish to change and insert the new value required. If you wish to create or modify the personalization, please refer to Chapter "Creation and editing of the personalization window".
  • Page 54 SCM-TLC 1) summary window of the 2) Function buttons station 4) Measurement 3) Measurement buttons 5) Control bar window Summary window of the station As you can understand from its name, it indicates the parts that compose the station (obviously as far as telemetry is concerned). When you click on the components (modules), the window with the data concerning measurements are displayed (3).
  • Page 55 SCM-TLC Function of the different buttons • "Alarm" button: The "Alarm" button enables to open the window showing the chronological list of the alarms that may have appeared (only for SCM and TLC units). Cancels alarms occurred in the station Print list of alarms Cancel database of alarms Close and return to...
  • Page 56 SCM-TLC • “Phone” button: The "Phone" button enables to open the window showing the set-up of the telephone numbers saved in the memory of the SCM. N.B. This option is only valid if the SCM is connected to an analogical modem. •...
  • Page 57 SCM-TLC • “General” button: The "General" button, enables to visualize the general measurements of the "Measurement window "(4). The measurements window: Measurement type Measurement name Received value • The "Type" column indicates the type of measurement: “In” -> analogical input, “InD”...
  • Page 58 SCM-TLC The control bar: The control bar is composed of 3 parts: • The control icons: The password: The first icon represents the password. If this icon is activated in the station a closed lock appears on a yellow background, otherwise it is open as shown on the picture.

  • Page 59: Programation Of A Remote Station

    SCM-TLC It enables to record in a database all the data received from the station. Its functioning is similar to this of a normal tape-recorder. • The comunication status icons: They enable to analize the status of the serial comunication. On the left, under the word "Comunication", the nod number and the identification number of the interrogated module are displayed.
  • Page 60 SCM-TLC Source of data displayed Type of data displayed Control buttons From this window it is possible: • To read and write the parameters of the remote station, • Enter and save the parameters in the database of the station itself. When the window is displayed it does not contain any data, it is necessary to read them from the remote station or from the database.
  • Page 61 SCM-TLC Press this button in order to read the parameters from the database of the station. Press this button in order to write the parameters in the database of the station. In this way, each station memorized in the Telecon software contains the programed parameters.

  • Page 62: Structure Of The Stations

    SCM-TLC 1.6 Structure of the stations. The Telecon software works exclusively with databases. Each station present in the Telecon, is composed of several blocks called Modules. Inside the program folder, there are four folders called: Default, Module, Phbook and Stations, which contain the database of the stations. Structure of the stations: \PHBOOK\ \STATIONS\...
  • Page 63 SCM-TLC When the program is started the database used situated in the folder \PHBOOK\ is shown, ex. "Group_A.mdb". Each group represents a series of stations. The database situated in the folder \PHBOOK\ contain the general information concerning the stations: telephone number, connection Baud Rate, COM port used, etc.

  • Page 64: Structure Of The Database

    \MODULE\Radio1\ folder which contain the information concerning the modules. 1.7 Structure of the database The TLC300 has one (or two) telemetry cards (8 balanced analogical inputs, 16 analogical/digital inputs and 8 relay outputs) and one I2C. When seen through the Telecon, each telemetry card present and each unit connected...
  • Page 65 SCM-TLC contains the data concerning the analogical inputs • Analog Output contains the data concerning the analogical outputs • Digital Input contains the data concerning the digital inputs • Digital Output contains the data concerning the digital outputs • General contains the data concerning the general measurements •...
  • Page 66 SCM-TLC Enable Input It is displayed on the Telecon grids Enable Display Name of the measurement Name Analogical 1 Name of the measurement Measure Unit Measure unit, Volt Conversion Type TENS/CORR Conversion for voltage and current measurements End Scale Value displayed when input at the maximum Start Scale Value displayed when input at the minimum Value after which the alarmis generated...

  • Page 67: Creation Of Groups And Stations

    SCM-TLC Max: value indicating the threshold for the generation of a visible alarm on the Telecon grids. Enable Input: value Yes/No which indicates whether it is possible to set a measurement value. Ex. When an input is selected it is on "No" because it is not possible to set an input value, while for measurements like i.e.
  • Page 68 SCM-TLC "Default" in case you have chosen not to copy the list of stations, otherwise you will find the same list of stations that composed the original group. 1.8.2 How to create a station From the main window, select the "Edit" button. The editing window of the station will be displayed.
  • Page 69 The steps for the creation of a station are the following: The chosen station is TX500 with telemetry. As already mentioned in Chapter 7, the station will be composed of three modules, 0 - TLC300 1 - PTX30LCD 2 - Telemetry of the PJ500MC It is necessary to create a new name in the Phone Book, which can be done by selecting button (3).
  • Page 70 SCM-TLC 4) Search the module "TLC300.mdb" in the list (7) 5) Click on the module and keep the left button of your mouse pressed, and drag it into the window (1). 6) The program will ask you whether you want to replace the selected module (Default) by the module you have chosen.
  • Page 71 SCM-TLC 7) In the window (6) "Md_00001.mdb"is displayed, which is the "TLC300.mdb" database renamed and copied in the folder \MODULE\Group1\. 8) Search the module "PTX30LCD.mdb" in the list (7). 9) Click on the module and keep the left button of your mouse pressed, and drag it...

  • Page 72: Creation And Editing Of The Personalization Window

    SCM-TLC In the window (6) "Md_00002.mdb" is displayed, which is the "PTX30LCD.mdb" database renamed and copied in the \MODULE\Group1\ folder. 11) Search the module "PJ500.mdb" in the list (7). 12) Repeat 8 and 9. You should obtain the situation shown in Figure: 13) The structure of the station is completed, so it is now necessary to connect it to a number from the Phone book.
  • Page 73 SCM-TLC Click on button "F4" situated on the window to enter the "edit" mode, the shape of the mouse cursor will change Click with the right button of your mouse to enter the menu with three options: Add Control. • To add a control View Grid.
  • Page 74 SCM-TLC The "Add Control" menu contains the submenus from where you can choose the items that can be added in the window: • Add Label. To add a label. • Add Measure. To add a numerical measurement (the use of the "Alpha Display") control is anyway advised Add Angular Gauge.
  • Page 75 In this brief instruction chapter, we will explain the operations which are necessary in order to create a personalization window. La station used as a reference will be a TX500 (TLC300, PTXLCD, PJ500MC) In order to add an instrument to indicate the output forward power.
  • Page 76 SCM-TLC If you require a maximum value inside the scale (in order to have an alarm led on the command, when the value is superior), write it in the "Max/Col" box. Ex: If you enter 760 as an "End scale" value and 600 as a "Max/Col" value, you will have a command as shown in the figure.
  • Page 77 SCM-TLC How to insert a led to indicate the presence of an SWR alarm. 1) From the menu "Add Control" select "Add Led". 2) 2. Select the module PJ500 in box "A". 3) 3. Among the "B" buttons, click on "InAna". 4) In box "C"...
  • Page 78 SCM-TLC The available colours are five: 0 - Black. 1 - Red. 2 - Yellow. 3 - Green. 4 - Blue. 6) Press the "Ok" button. 7) If necessary, position the led in the place required. 8) Repeat the same procedure in order to insert a label with the name of the alarm. We will now create two buttons to switch on and off the transmitter.
  • Page 79 SCM-TLC Now you just have to save the window by clicking on the right button of your mouse and choosing "Save Window". User Manual Rev. 1.0 - 17/01/03 31 / 50...
  • Page 80 SCM-TLC This page was intentionally left blank 32 / 50 Rev. 1.0 - 17/01/03 User Manual...

  • Page 81: Monitoring Telemetry Stations

    SCM-TLC 2. Monitoring Telemetry Stations 2.1 Functioning This is a telemetry software that gives the possibility to call automatically and cyclically every station from a list of stations, having their status displayed in a very simple and clear way and indicating which station is in alarm and the type of alarm. Morevover, it is possible to have the software calling a station after having been informed by an SMS, and have its status displayed immediately.
  • Page 82 SCM-TLC List of Stations (A) Map of the Stazioni (B) Brief Map (C) 2.3.1 List of Stations (A). In this list all the stations that concern a customer are displayed. They are sorted in the following way: presence on the map, priority, frequency of calls and station number in the database.
  • Page 83 SCM-TLC When clicking with the right button of your mouse on the icon indicated above, a cascade menu will display the following functions: When selecting " Call Station " the immediate call will be made and the consequent data will be updated. When selecting "Reset Station"...
  • Page 84 SCM-TLC When choosing " Properties" a sub-menu with 2 possible choices is displayed: " Scheduling Manager" which displays a window for the setting of scheduling parameters and priority calls. Such priority will also be used put the stations in order in the list (A);...

  • Page 85: Scheduling Functions

    SCM-TLC 2.4 Scheduling functions The Scheduling is structured in the following way: 1) The parameters that can be modified in the station are: Frequency of the calls, being possible to choose among the following values: • 1 - 3 times a day (morning, afternoon and evening) 2 - once a day, morning 3 - once a day, afternoon 4 - once a day, evening...
  • Page 86 SCM-TLC Priority. The priority will be selected through a slider having three positions (high, • medium, low) that the customer may use to set the order in which calls should be made. Basically, if some stations are more important than others, it will be necessary to assign to this station a priority higher than the priority of other stations.

  • Page 87: Technical Information Concerning The Realization

    SCM-TLC Where these icons appear: indicates that the station is working correctly. • • indicates that the station is in alarm. indicates that the maximum number of retries was reached. • • indicates that the program is making a retry. There are also three other symbols used in the list (A): •...
  • Page 88 SCM-TLC The area 3 will be used in order to define the position of a given station in the list (A) and therefore the order for the automatic calls. 4) Frequency of station calls according to the scheme: 0 - 3 times a day (morning, afternoon and evening) 1 - once a day, morning 2 - once a day, afternoon.
  • Page 89 SCM-TLC 2) String received with alarms. 3) Byte indicating the number of alarms present. 4) Date of the last connection. 5) Time of the last connection. 6) Status of the station at the last connection (see point 8) Each station present in the Phone_Book table will have a corresponding configuration table as shown in point B.
  • Page 90 SCM-TLC This page was intentionally left blank 42 / 50 Rev. 1.0 - 17/01/03 User Manual...

  • Page 91: Interconnection Example (Tlc)

    The amplifiers will follow all then. • The Type that identified the digital cards are described in the following table: Type Nome None PTX30LCD SCM4 TLC300/2000 SCM1 PTX60LCD PTX100LCD TLC tube PTRL NV RXRL NV Telemetry card type 1 Telemetry card type 2...

  • Page 92: In Analogic With Rvr's Lcd Equipment

    SCM-TLC 3.2 In Analogic with RVR’s LCD Equipment To connect different RVR’ base equipment between they, that aren’t digital, is necessarily use an IB (see accessories), that allows the redistribution of the signals them coming from the equipment in order to make them to reach in right way on the inputs of the TLC.
  • Page 93 SCM-TLC 3.3.1 How to control a D.C.voltage superior to 5V Connect to DB25 marked as BALANCED ANALOG INPUT on the PIN described in the table Pin number Meant Adj. Trimmer Analogic balanced input n°1 2 (+), 14 (−) Analogic balanced input n°2 3 (+), 16 (−) 5 (+), 17 (−) Analogic balanced input n°3...
  • Page 94 SCM-TLC 3.3.3 How use the relay outputs Remembering that in figure is represented schematically the Off relay condition and that the disposition of the contacts in the connector is described in the following table. Pin number Meant 1 (C), 14 (NC), 2 (NO) Relay n°1 15 (C), 3 (NC), 16 (NO) Relay n°2...

  • Page 95: Commands From Remote (Tlc)

    SCM-TLC 4. Commands from remote (TLC) Through these commands sends under form of SMS they could be modified the states of any exits and activate any functions of the TLC. •INFO: Sending this message as SMS from any mobile phone, you must have in answered an other SMS with the number and name of the station, the forward and reflected power present in percentage and the currents alarms.
  • Page 96 SCM-TLC This page was intentionally left blank 48 / 50 Rev. 1.0 - 17/01/03 User Manual...

  • Page 97: Massages On The Modem State (Only Tlc2000)

    SCM-TLC 5. Massages on the Modem State (only TLC2000) In this section is described the visualization of the messages state on the display regarding the modem. These messages could be in the angle aloft to the right of the display, on the frontal panel (only of TLC2000) and they inform on the modem current state.
  • Page 98 SCM-TLC This page was intentionally left blank 50 / 50 Rev. 1.0 - 17/01/03 User Manual...
  • Page 99 Questa parte del manuale contiene i dettagli tecnici riguardanti la costruzione delle singole schede componenti il TLC300. L’appendice è composta dalle seguenti sezioni: This part of the manual contains the technical details about the different boards of the TLC300.
  • Page 100 TLC300 Appendice Tecnica Rev. 1.1 - 27/05/03 CSTLSCCPU002 - 1 / 4...
  • Page 101 TLC300 2 / 4 - CSTLSCCPU002 Rev. 1.1 - 27/05/03 Technical Appendix...
  • Page 102 TLC300 Main card TLCSCM Bill Of Materials Page1 ItemQuantity Reference Part ____________________________________________________________________________________________ TMB-05 CN04MR C1,C2,C13,C24,C30 47uF C3,C11,C14,C16,C17,C19, 0.1uF C21,C22,C28,C29,C31,C32, C33,C34,C55,C58,C59,C61, C62,C63,C64,C65,C68,C70 C4,C10,C12,C15,C25,C60, 10uF C66,C67 C5,C6,C8,C9 220nF C7,C56A 100nF CV30pF C27,C20 22uF 100uF C35,C36,C37,C38,C39,C40, 100pF C41,C42,C43,C44,C45,C46, C47,C48,C49,C50,C51,C52, C53,C54 0.1F 470pF D2,D1...
  • Page 103 TLC300 R1,R2,R3,R4,R14 22K0 R5,R17,R47,R48 10K0 R6,R7,R8,R9,R10,R11,R12, R18,R21 R16,R24,R34,R35,R36,R37, 4K70 R45,R46 R19,R20 R38,R22 R23,R29 R25,R26,R50 22K1 R31,R32,R33 10H0 220H0 R40,R41 2M20 R42,R43 330H0 47H0 SW1,SW2,SW3 SWDIP8 7407 74HC138 U3,U8,U15 74HC541 U4,U5 74HC574 7406 7805 MB3773 PCF8594 PCF8598 U14,U13 LM358N 4 / 4 - CSTLSCCPU002 Rev.
