User's Manual
Cyber Power Systems, Inc.
www.cyberpower.com
OL6000ERT3UDM
OL8000ERT3UDM
OL10000ERT3UDM
K01-0000407-01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OL6000ERT3UDM and is the answer not in the manual?

Questions and answers

Related Manuals for Cyber Power OL6000ERT3UDM

Summary of Contents for Cyber Power OL6000ERT3UDM

  • Page 1 User’s Manual OL6000ERT3UDM OL8000ERT3UDM OL10000ERT3UDM Cyber Power Systems, Inc. www.cyberpower.com K01-0000407-01...

  • Page 2: Important Safety Instructions

    REQUIRED PRECAUTIONS. KEEP UNAUTHORIZED PERSONNEL AWAY FROM BATTERIES! CAUTION! Do not use an improper size power cord as it may cause damage to your equipment and cause fire hazards. Copyright © 2014 Cyber Power Systems, Inc.
  • Page 3 Rackmount right rail * 2 sets Plastic washers (8) * 2 sets Phone line Screw hole dust covers (10) * 2 sets PowerPanel® Business Edition software CD USB communication cable Serial Interface Cable (RS-232) Copyright © 2014 Cyber Power Systems, Inc.

  • Page 4: Hardware Installation

    Step 5: Place the internal battery trays back into the Battery module (See page 16) Once completed, perform the same steps for the Power module. CAUTION! The Battery module must be installed below the Power module. Copyright © 2014 Cyber Power Systems, Inc.

  • Page 5: Vertical/Tower Installation

    CAUTION! Do not work alone under hazardous conditions. CAUTION! In case of the risk of electric shock, do not remove the top cover. CAUTION! The battery can energize hazardous live parts inside even when the AC input power is disconnected. Copyright © 2014 Cyber Power Systems, Inc.

  • Page 6: Installing Your Ups System

    UPS will continuously emit two beeps per second. For resetting the unit, unplug some equipment from the outlets. Make sure your equipment carries a load current within the unit’s safe range, (refer to the technical specifications). Copyright © 2014 Cyber Power Systems, Inc.

  • Page 7: Hardwiring The Input/ Output Terminals

    CAUTION! Disconnected EPO will immediately shut down the logic circuit output of the UPS. Wiring the EPO signal is optional. CAUTION! Local safety rules may require a separate, external EPO to turn off output circuit breakers. Refer to local wiring rules, the EPO should use approved components. Copyright © 2014 Cyber Power Systems, Inc.
  • Page 8 Insert the input cable through the appropriate cable gland (not included). Step 3: Bypass configuration (for dual input configuration) Remove the interconnection wires (Jumper) on bypass terminals (J / L) and insert the bypass cable through the appropriate cable gland (not included). Copyright © 2014 Cyber Power Systems, Inc.
  • Page 9 Step 6: Fix the top cover on the bottom cover Insert the output cable through the appropriate cable gland (not included) Tighten the two screws to fix the top cover on the bottom cover. Copyright © 2014 Cyber Power Systems, Inc.

  • Page 10: Backfeed Protection

    3. Hardwire the input terminals and “Backfeed Protection Connector” as shown in the following diagram. 4. The external isolation device must be installed in the Mains path. Mains L N PE IP-L IP-N PSDR 2A Fuse Backfeed (Slow Blow) AC-L AC-N Copyright © 2014 Cyber Power Systems, Inc.

  • Page 11: Basic Operation

    13. SNMP/HTTP Network slot fault in the bypass circuit. Slot to install the optional SNMP card for remote network control and monitoring. 14. Extended Runtime Battery Module Connector Connection for additional CyberPower XL Battery modules. Copyright © 2014 Cyber Power Systems, Inc.
  • Page 12 Step 3: Rotate the battery cable retention bracket and tighten the two screws to fix battery cable. Step 4: Use a power cord to plug AC input inlet of the battery module into a wall receptacle. Copyright © 2014 Cyber Power Systems, Inc.
  • Page 13 Step 4: Rotate the battery cable retention bracket and tighten the two screws to fix battery cable. Step 5: Use a power cord to plug AC input inlet of the 2 battery module into AC output outlet of the 1 Battery module. Copyright © 2014 Cyber Power Systems, Inc.

  • Page 14: Led Indicators - Ups Status

    Press this button to scroll up in the LCD menu. ▼ Press this button to scroll down in the LCD menu. ENTER Press this button to select an option. Press this button to cancel or return to previous LCD menu. Copyright © 2014 Cyber Power Systems, Inc.

  • Page 15: Lcd Setup Functions

    Displays the present Date & Time - - - - / - - / - - - -:- - Next BAT Change Displays the next Battery Change Date & Time XXX / XXXX Copyright © 2014 Cyber Power Systems, Inc.

  • Page 16: Lcd Event Log

    You may be prompted to save the selection, if so press the “ENTER” button to save the setting. Some options are saved and started automatically. (See the following table for additional details.) Press the “ESC” button to cancel or return to the previous LCD menu. Copyright © 2014 Cyber Power Systems, Inc.

  • Page 17: Eco Mode

    Configure “Audible Alarms” as “Disable” on the LCD module and it will stop warning of any malfunction audibly. MANUAL BATTERY TEST Configure “Battery Test” as “Active” on the LCD module; and it will perform the “Manual Battery Test” Copyright © 2014 Cyber Power Systems, Inc.

  • Page 18: Lcd Module Remote Control And Wall-Mounting Instructions

    Step 4: Mount LCD Module on the Wall SAFETY PRECAUTIONS CAUTION! It must be done by qualified personnel. CAUTION! To avoid electric shock, turn off and unplug the unit before installing REMOTE CONTROL or WALL-MOUNTING INSTRUCTIONS. Copyright © 2014 Cyber Power Systems, Inc.

  • Page 19: Maintenance

    Step 4: Insert the battery connectors and tighten the screws of battery retaining cover Step 5: Install the front panels Copyright © 2014 Cyber Power Systems, Inc.

  • Page 20: Manual Bypass Switch Operation

    The UPS shutdown safely and it can perform routine maintenance or shows “Generator On” or “Converter On”. replacement now. CAUTION! Do not turn the Manual Bypass Switch when hearing a warning beep from the UPS. Copyright © 2014 Cyber Power Systems, Inc.

  • Page 21: Technical Specifications

    L x W x H = 26 x 17 x 5.2in. (66 x 43.3 x 13.2cm) Dimensions--Battery Module L x W x H = 26 x 17 x 5.2in. (66 x 43.3 x 13.2cm) Net Weight--Power Module 53lbs(24Kg) Net Weight--Battery Module 167.2lbs(76Kg) 171.6lbs(78Kg) Safety Conformance Approvals CE, C-tick Copyright © 2014 Cyber Power Systems, Inc.

  • Page 22: Troubleshooting

    Internal DC bus voltage is too high or too low. Cyber Power Systems, Inc. www.cyberpower.com © Entire contents copyright 2014 Cyber Power Systems, Inc., All rights reserved. Reproduction in whole or in ® ® part without permission is prohibited. PowerPanel Business Edition and PowerPanel Personal Edition are trademarks of Cyber Power Systems, Inc.
