Chapter 2 — Operation
Replacing the Battery Pack
To replace an empty battery pack with a charged one, proceed as follows:
Switch off the battery unit.
1
Turn the printer around so you can access its rear side.
2
Release the spring lock and pull out the battery pack.
3
Insert a charged battery pack in the same slot and check that it is held
4
by the spring lock.
Switch on the battery unit.
5
Power supply
adapter (PSA)
Battery pack
Spring lock
8
EasyCoder PC4/PC41 Mobile Battery Unit Installation Instructions
Cable
