Silbury - bed 3"
Assembly Instructions - Please keep for future reference
Dimensions
Width : 200,8
Depth : 97,3
Height : 110,0
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
368603067
4083690
03456 400 800
Advertisement
Related Manuals for Argos Silbury 4083690
Summary of Contents for Argos Silbury 4083690
- Page 1 Silbury - bed 3" Assembly Instructions - Please keep for future reference 4083690 Dimensions Width : 200,8 Depth : 97,3 Height : 110,0 Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400 800 368603067...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on components and tools listed on the product, this could cause pages 3 and 4. damage.
- Page 3 If you have damaged or missing components, call Components - Panels the Argos Customer Helpline: 03456 400 800 Please check you have all the panels listed below footboard headboard upright x6 footboard legs x2 V198107 V160115 V540005 865x115x19 mm 435x64x15 mm...
- Page 4 Components - Fittings If you have damaged or missing components, call the Argos Customer Helpline: 03456 400 800 Please check you have all the panels listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 Assembly Instructions Step 1 Pour a drop of glue K into the holes indicated on the headboard upright 1 before knocking the dowels A into the holes using a small hammer. Step 2 Knock the dowels A into the holes indicated on the headboard 6 and 7 using a small hammer.
- Page 6 Assembly Instructions Step 4 Insert the screw bush B into the holes indicated on the footboard legs 2 and the headboard legs 3 and 4 using the allen key N. Step 5 Screw the sector screw D into the holes indicated on the footboard legs 2 and the headboard legs 3 and 4 using a flatblade...
- Page 7 Assembly Instructions Step 6 Push the footboard legs 2 onto the footboard 5. Step 7 Insert the sector C into the holes indicated on the footboard 5 as shown. Fix the footboard legs 2 to the footboard 5 by twisting the sector screw D using the sector key L.
- Page 8 Assembly Instructions Step 8 Pour a drop of glue K into all the holes indicated on the headboard 6 before placing the headboard upright 1. Push tightly together. Step 9 Fix the 2nd headboard 6 by following the instructions in step 8. All 6 pieces in one step.
- Page 9 Assembly Instructions Step 11 Insert the sector C into the holes indicated on the headboard 6 and 7 as shown. (4 of them are located on the opposite side) Fix the headboard legs 3 and 4 to the headboard 6 and 7 by twisting the sector screw D using til sector key L.
- Page 10 Assembly Instructions Step 13 Push the bed side 8 onto the headboard and the footboard as shown. Ensure that both the headboard and the footboard are faced correctly. Step 14 Insert the sector C into the holes indicated on the bed side 8 as shown. Fix the bed side 8 to the footboard and the headboard by twisting...
- Page 11 Assembly Instructions Step 15 Place the slats 10 onto the rail 9. Ensure there is approximately the same distance between the slats. Fix the slats using the screw H. Step 16 Place the cap J onto the holes on the headboard Assembly is complete.
