Characteristics

• single thermostat with possibility of temperature management in adjustable
range (it is possible to modify this range or make a special one on request)
• it is used to regulate heating (or cooling) in demanding environments (outside,
humidity, dustiness, etc.)
• thermostat is placed in water-proof box with IP65, which enables installation
outside, with in-built sensor (included in the supply)
• TEV-2 - control and indication elements are placed under transparent cover,
TEV-3 - control and indication elements are placed directly on the cover (for easy
orientation and frequent change of temperature)
• thermostat status is indicated by LED (2 colours)
• function of monitoring sensor disconnection and short-circuit
• output changeover contact 16 A (AC1)

Description

TEV-2 - without cover
4
5
1. Device status indication
2. Temperature setting
3. Terminal for sensor
4. Terminals for connection of supply voltage and output contact
5. Sleeve for incoming cables
6. Sensor TZ-0
7. Sensor TC-0
cos φ ≥ 0.95
Type of load
AC1
Mat. contacts AgNi,
contact 16 A
250V / 16A
Type of load
AC13
Mat. contacts AgNi,
contact 16 A
250V / 6A
TEV-3 - cover
1
2
3
5
6
M M
AC2 AC3
250V / 5A 250V / 3A
K
AC14 AC15
250V / 6A 250V / 6A
TEV-2
TEV-3
Thermostat
Symbol
Connection
Function heating
1
2
Function cooling
7
AC5a
AC5a
uncompensated compensated
x
230V / 3A (690VA)
M
DC3
DC1
24V / 6A
24V / 16A
1 / 2
L
T
°C
T
N V2 V1
HAL.230V
AC5b AC6a
800W x 250V / 3A
M
DC5 DC12
24V / 4A 24V / 16A
EN
AC7b AC12
250V / 10A
DC13 DC14
24V / 2A 24V / 2A
