Reference time
Resolution
1. Due to a hardware limitation, PPS (Timing) signals are discrete with a resolution of 20 ns. LGG100-

Connector Specifications

Power Connector

www.javad.com
Table B-2. GNSS Board's Specifications
GG receiver, however, allows you to compensate for this "discreteness error". You can force the
receiver to generate for each PPS (Timing pulse) a message containing the offset between the scheduled
PPS (Timing pulse) time and the actual pulse edge's arrival time. When the pulse edge is advanced
relative to the scheduled time, the offset is positive. When the pulse edge is delayed relative to the
scheduled time, the offset is negative. The accuracy of the measured offset is 2 ns.
This sections list LGG100-GG connector details.
The power connector (Figure B-1) is a sealed receptacle, 5 pin, ODU p/n
G80F1C-T05QF00-0000.
Table B-3 gives power connector specifications.
Table B-3. Power Connector Specifications
Number
1 Power_INP
2 Power_INP
3 Power_GND
4 Power_GND
5
GPS, GLONASS, UTC (USNO), UTC (SU)
5 ns
Figure B-1. Power Connector
Signal Name
+9 to +35 volts DC input
+9 to +35 volts DC input
Ground, power return
Ground, power return
Not used
A P P E N D I X
Specifications
Details
LGG100-GG Operator's Manual 85
