MIDEA SERVICE MANUAL
VACUUM CLEANER
MODEL: V18P01FP25NA TYPE
December, 2020
This document is published to be used for after sales service only. The content are subject
to change without prior notice.
In interest of user safety the appliance should be restored to its original condition and only
parts identical to those should be applied.
Midea Kitchen Appliance

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V18P01FP25NA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Midea V18P01FP25NA

Summary of Contents for Midea V18P01FP25NA

  • Page 1 MIDEA SERVICE MANUAL VACUUM CLEANER MODEL: V18P01FP25NA TYPE December, 2020 This document is published to be used for after sales service only. The content are subject to change without prior notice. In interest of user safety the appliance should be restored to its original condition and only parts identical to those should be applied.

  • Page 2: Table Of Contents

    CONTENTS WARNING ..................................3 PRODUCT ..................................3 1. Model ..................................3 2. Operation Methods ............................3 SERVICE ................................... 4 1. System Diagram..............................5 Components ............................5 2. Maintenance ................................ 5 2.1 Tool & Measure Instrument........................5 2.2 Assembly & Disassembly ........................6 2.2.1 Check of Motor ..........................

  • Page 3: Warning

    WARNING This service information is designed for experienced repair technicians only and is not designed for use by the general public .It does not contain warning or cautions to advise non-technical individuals of potential dangers in attempting to service a product .Products powered by electricity should be serviced or repaired only by experienced professional technicians .Any attempt to service or repair the product or products dealt with in this service information by anyone else could result in serious injury or death.

  • Page 4: Service

    1. Align metal tube set with the electric brush, and insert it until you hear a “click” sound. 2. Align body set with t metal tube, and insert it until you hear a “click” sound. * Note: Different models may have different methods of assemble, please refer to the instruction manual for specific models.

  • Page 5: System Diagram

    1. System Diagram 1.1 Components [1] Power Button [6] Release Button for metal tube [2] 2-stage Power Adjustment Button [7] Metal tube [3] cup Release Button [8] Release Button for Brush [4] Dust Cup [9] Electrical Brush [5] Release Button for Dust Empty [10] Release Button for battery pack * Note: Different models have different components, please refer to the instruction manual for specific models.

  • Page 6: Assembly & Disassembly

    1. Wrench 2. Hexagon Bar Wrench 3. Multi-meter 4. +/- Screw Drivers 2.2 Assembly & Disassembly 2.2.1 Check of Motor...

  • Page 7: Assembly Of Motor

    (1) Check the motor can work well with no rust on its surface. 2.2.2 Assembly of Motor (1) Install the seal ring on the motor assembly. (2) Install inlet grid on the motor assembly.

  • Page 8: Assembly Of Pcb

    (3) Combine the motor assembly and the body assembly. (4) Install the combination inside the body assembly. 2.2.3 Assembly of PCB...
  • Page 9 (1) Install the PCB into the battery body . (2) Insert the terminals onto the PCB. (3) Close the top body and button body together,install 4 screws.

  • Page 10: Assembly Machine Body

    2.2.4 Assembly Machine Body (1) Install the battery pack (2) Install the dust cup assembly...

  • Page 11: Error Code & Trouble Shooting

    2.3 Error Code & Trouble Shooting 2.3.1 EC01: Vacuum Cleaner Cannot Work The power source is abnormal. Change power source. The circuit connection is loosen Tight the connection or change or short circuit. the wire. The On/Off button cannot work. Replace a new On/Off button.

  • Page 12: Ec02: Start Directly After Plugging In

    2.3.2 EC02: Start Directly after Plugging in The On/Off button can stop the Stop the vacuum cleaner and vacuum cleaner. restart again. The circuit connection is loosen Tight the connection or change or short circuit. the wire. The PCB cannot work. Replace a new PCB.

  • Page 13: Ec03: Low Suction Pressure

    2.3.3 EC03: Low Suction Pressure The seal ring is installed not Reinstall the seal ring or replace tightly or broken. a new one. There is block in the hose. Clean the hose. There is block in the suction Clean the suction mouth. mouth.

  • Page 14: Ec04: Smoky Motor

    2.3.4 EC04: Smoky Motor The power source is not stable. Change a new power source. The circuit connection is loosen Tight the connection or change or short circuit. the wire. The vacuum cleaner is used to It’s not allowed as instructed in clean liquid or metal materials.

  • Page 15: Ec05: Dust Leakage

    2.3.5 EC05: Dust Leakage The dust bag/cup is broken. Replace a new Dust bag/cup. Fix it tightly or replace a new Seal The seal ring is broken or loose. ring. The front cover is broken or loose. Fix it tightly or replace a new front cover.

  • Page 16: Attached Files List

    ATTACHED FILES LIST 1. Exploded View 2. Spare Parts List 3. Wiring Diagram * Note: The manual may update without prior notice. Please download the latest version on website: https://tsp.midea.com.
